1920x1200 uncompressed dvi over cat5e/6 kvm extender - 330ft (100m)
Hide thumbs Also See for SV565UTPHDU:

Advertisement

Quick Links

1920x1200 Uncompressed DVI over
Cat5e/6 KVM Extender - 330ft (100m)
SV565UTPHDU / SV565UTPDUV
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 06/27/2014
*actual product may vary from photos

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SV565UTPHDU and is the answer not in the manual?

Questions and answers

Summary of Contents for StarTech.com SV565UTPHDU

  • Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 06/27/2014...
  • Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
  • Page 3: Table Of Contents

    Introduction ....................2 Packaging Contents ..........................2 System Requirements ..........................2 Product Overview ..................3 Front View - SV565UTPHDU ........................3 Rear View - SV565UTPHDU ........................3 Front View - SV565UTPDUV ........................4 Rear View - SV565UTPDUV ........................4 LED Indicators............................. 5 Cabling ................................
  • Page 4: Introduction

    Introduction Packaging Contents • 1 x Local Extender Unit • 1 x Remote Extender Unit • 2 x Mounting Brackets • 1 x HDMI Cable • 1 x USB Cable • 2 x Universal Power Adapters • 6 x Power Cords (2 sets, NA/EU/UK) •...
  • Page 5: Product Overview

    Product Overview Front View - SV565UTPHDU Rear View - SV565UTPHDU Local Unit Remote Unit Instruction Manual...
  • Page 6: Front View - Sv565Utpduv

    Front View - SV565UTPDUV Rear View - SV565UTPDUV Local Unit Remote Unit Instruction Manual...
  • Page 7: Led Indicators

    LED Indicators On: The system is powered and ready to use Power LED (Green) Off: The system is not powered On: Local and Remote extenders are able to communicate across the link Link LED (Green) Off: There is no communication between the local and remote extenders On: The local extender and the host computer are communicating with each other and working...
  • Page 8: Installation

    Installation Hardware Installation Preparing your site 1. Determine where the computer is to be located and set up the computer. 2. Determine where you want to locate the remote desktop, including the monitor, keyboard, mouse and any other USB device(s). 3.
  • Page 9 Installing the Remote Extender Unit 1. Place the remote extender unit near the monitor and USB device(s) in the desired remote location. 2. Connect an HDMI/DVI cable (not included) to the remote extender (HDMI/DVI Out) to the monitor. 3. Plug your USB Device(s) into the USB ports on the remote extender. Connecting the Local Extender to the Remote Extender With Surface Cabling 1.
  • Page 10: Verifying Installation

    Cat 5e (or better) UTP Connecting Power to the Local and Remote Extenders 1. Plug the supplied 5V, 3A power adapter into a suitable AC outlet near the local extender. 2. Connect the power adapter to the local extender. 3. Plug the supplied 5V, 3A power adapter into a suitable AC outlet near the remote extender.
  • Page 11: Troubleshooting

    2. Check to see if the USB LED is on and the Video LED is blinking or on, if they are not, this indicates there is no USB data or video data. Check the video and USB connections to the host computer, and the video connection to the monitor. Check to see if any USB devices are connected to the remote extender.
  • Page 12 PROBLEM CAUSE SOLUTION Link LED on local • The host computer is 1. Disconnect all USB devices from extender is on, the remote extender. not powered on. USB LED on local 2. Disconnect the local extender • The local extender is extender is off from the computer.
  • Page 13 PROBLEM CAUSE SOLUTION All LEDs on • The USB device is 1. Disconnect the KVM extender both the local product from the computer. malfunctioning. and remote 2. Connect the USB device directly • The computer does extenders are to the USB port on the computer. not recognize the USB on, but the USB 3.
  • Page 14 PROBLEM CAUSE SOLUTION Video frames are • The extender is not 1. Contact Technical Support. being dropped compatible with HDMI. Video LED is off • One or both of the 1. Confirm extender operation with HDMI/DVI cables that are less HDMI/DVI cables are than 5m (16’...
  • Page 15: Specifications

    Specifications SV565UTPHDU SV565UTPDUV Video Signal HDMI Local Extender Unit: Local Extender Unit: 1 x HDMI (19-pin) female 1 x DVI-D (24-pin) female 1 x USB type B female 1 x USB type B female 1 x RJ45 female 1 x RJ45 female...
  • Page 16: Technical Support

    Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
  • Page 17 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
