Step 5 - Set the Date and Time and Video Mode
This will allow the images taken by GuardCam to display
the correct date and time it was taken.
Push TIME/DATE SET button (see Fig. 10) for 3 seconds,
The LCD screen will then flash 3 times, indicating you
have entered Time/Date setting mode.
1. "YEAR"setting: "Y" and "08" are displayed on the screen;
push the button to set year from "08-99", push the
button again and hold for 3 seconds to scroll through
numbers quickly. If you have not pressed the button for
3 seconds, it will automatically save the year and go on
to allow you to set the month.
Repeat the same setting procedure for
MONTH / DATE / HOUR / MINUTE / VIDEO MODE.
2. Video mode setting: automatically at the end of the time date setting two icons
and
"P" (Photo).
On the "P" (photo) setting, GuardCam will take a series of digital photographs at a
rate of 1– 3 photos every second when the motion sensor is triggered.
On the "V" (video) setting, GuardCam will take a 20 second video clip when the
motion sensor is triggered.
Please note that in the event of a mains power failure GuardCam will revert to
the factory setting of "V".
If you have not pushed any buttons for 3 second, "OK" will appear on the screen,
indicating it has automatically saved the current settings. The LCD screen will
shut off automatically 10 seconds later.
Please note that in the event of a mains power failure in excess of 72
hours the time and date settings must be reset.
"V" appear on the screen; push the button to choose "V" (Video) or
1. START
3. MONTH
Setting
HOUR
Setting
VIDEO/PHOTO
Setting
Fig. 10
2. YEAR
Setting
4. DATE
Setting
MINUTE
Setting
FINISH
9
