ACV The Challenger Installation And Maintenance Manual

Combination boiler and/or water heater
Hide thumbs Also See for The Challenger:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User's Information Manual
Combination
Boiler
Water Heater
* I N S T A L L A T I O N A N D M A I N T E N A N C E *
* I N S T A L L A T I O N A N D M A I N T E N A N C E *
NOTI E
Warranty Registration Card must be filled out by the customer and mailed within thirty (30) days of installa-
tion in order to gain warranty coverage.
When receiving the CHALLENGER, any claims for damage or shortage in shipment must be filed immedi-
ately against the transportation company by the consignee.
Leave all documentation received with appliance with owner for future reference.
If the information in this manual is not followed exactly, a fire or explosion may
WARNING
result causing property damage, personal injury or death.
• Do not store or use gasoline or other flammable vapors and liquids in the vicinity of
• WHAT TO DO IF YOU SMELL GAS
Installation and service must be performed by a qualified installer, service agency or the
gas supplier.
Date: 11/25/13
and or
/
M A N U A L
M A N U A L
this or any other appliance.
- Do not try to light any appliance
- Do not touch any electrical switch; do not use any phone in your building.
- Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
- If you cannot reach your gas supplier, call the fire department.
FOR YOUR SAFETY
2010-1Challenger Manual
