Vertex Standard VXR-7000 Service Manual page 67

Parts Layout
A
1
2
a
1
2
B C
b c
D
MB15A02PFV
(Q3001)
UN5215 (8E)
(Q3004)
Side A
MA143 (MC)
(D3015, 3016)
RN739F (5F)
d
(D3003)
XN1213 (9L)
(Q3016, 3020, 3022)
HZM5.6NB2 (562)
(D3014)
Side B
RX Unit (Lot. 1-59)
TA31136FN TA78L05UA (8C) 2SK508 (K52)
(Q3012) (Q3021) (Q3008)
2SA1586Y (SY) 2SC4116GR (LG) 2SC3357 (RK)
(Q3003) (Q3002, 3015) (Q3005, 3011)
2SC5226 (R22)
(Q3009, 3014)
GN2011-Q (4W)
(D3011)
2SA1586Y (SY) 2SC2812 (L6) 2SB1122S (BE)
(Q3007) (Q3013) (Q3018)
2SC4116GR (LG)
(Q3006, 3010)
MA142WK (MU) MA143 (MC) 1SS302 (C3)
(D3012, 3013) (D3017, 3018) (D3001)
67
