Vertex Standard VXR-7000 Service Manual page 20

(uhf) desktop repeater
Hide thumbs Also See for VXR-7000:
Table of Contents

Advertisement

Enlarged version
Exploded View & Miscellaneous Parts (Lot.71-)
Heat sink PA-2 ASSY (vxstd p/n: CS1861002)
Heat sink PA-2 ASSY
CS1861002
Main Heat Sink Plate
(No Part # and impossible to purchase this part only)
Rubber Spacer
Heat Sink Plate
Screws M2.6X5
RA0766400
RA0766900
U32450001
20
