Vertex Standard VXR-7000 Service Manual page 118

Filter Unit (50W Type)
Parts List
REF. DESCRIPTION
R 6015 CHIP RES.
R 6016 CHIP RES.
R 6018 CHIP RES.
R 6019 CHIP RES.
R 6020 CHIP RES.
R 6021 CHIP RES.
R 6022 CHIP RES.
R 6023 CHIP RES.
R 6024 CHIP RES.
R 6025 CHIP RES.
R 6026 CHIP RES.
R 6027 CHIP RES.
R 6028 CHIP RES.
R 6029 CHIP RES.
R 6030 CHIP RES.
R 6031 CHIP RES.
R 6033 CHIP RES.
RL6001 RELAY
RL6003 RELAY
T 6001 TOROIDAL COIL
T 6003 TOROIDAL COIL
RUBBER
118
VALUE V/W TOL.
10k 1/16W 5%
68k 1/16W 5%
18k 1/16W 1%
100k 1/16W 1%
10k 1/16W 5%
10k 1/16W 5%
18 1/2W 5%
56k 1/16W 5%
22k 1/16W 5%
180 1/16W 5%
3.3k 1/16W 5%
1.8k 1/16W 5%
10k 1/16W 5%
2.2k 1/16W 5%
22k 1/16W 5%
22k 1/16W 5%
100k 1/8W 5%
DC12V
DC12V
MFR'S DESIG VXSTD P/N
RMC1/16 103JATP J24185103
RMC1/16 683JATP J24185683
RMC1/16 183FTP J24183183
RMC1/16 104FTP J24183104
RMC1/16 103JATP J24185103
RMC1/16 103JATP J24185103
RMC1/2 180JTE J24275180
RMC1/16 563JATP J24185563
RMC1/16 223JATP J24185223
RMC1/16 181JATP J24185181
RMC1/16 332JATP J24185332
RMC1/16 182JATP J24185182
RMC1/16 103JATP J24185103
RMC1/16 222JATP J24185222
RMC1/16 223JATP J24185223
RMC1/16 223JATP J24185223
RMC1/8T 104J J24215104
ACP131 DC12V M1190152
ACP131 DC12V M1190152
D12A RI16X8X8 L0022119
D12A RI16X8X8 L0022119
RA0217100
VERS. LOT. SIDE LAYADR
1- A C3
1- A C3
1- A C3
1- A C3
1- A C3
1- A C3
1- A D3
1- A D2
1- A D2
1- A D3
1- A D2
1- A D2
1- A D3
1- A C3
1- A C3
1- A C3
1- A C3
1- A C1
1- A C2
1- A A3
1- A B2
16-
