Vertex Standard VXR-7000 Service Manual page 105

REF. DESCRIPTION
PCB with Components
Printed Circuit Board
C 5001 CHIP CAP.
C 5002 CHIP CAP.
C 5003 CHIP CAP.
C 5004 CHIP CAP.
C 5005 CHIP CAP.
C 5006 CHIP CAP.
C 5007 CHIP CAP.
C 5008 CHIP CAP.
C 5009 CHIP CAP.
C 5010 CHIP TA.CAP.
C 5011 CHIP CAP.
C 5012 CHIP CAP.
C 5013 CHIP CAP.
C 5014 CHIP CAP.
C 5015 CHIP CAP.
C 5016 CHIP TA.CAP.
C 5017 CHIP CAP.
C 5018 CHIP CAP.
C 5019 CHIP TA.CAP.
C 5020 CHIP CAP.
C 5021 CHIP CAP.
C 5022 CHIP CAP.
D 5001 LED
D 5002 LED
D 5003 DIODE
D 5005 DIODE
D 5006 DIODE
D 5007 DIODE
D 5008 DIODE
D 5009 DIODE
D 5010 DIODE
D 5011 DIODE
D 5012 LED
D 5013 LED
D 5014 DIODE
D 5015 DIODE
D 5016 DIODE
D 5017 DIODE
D 5018 DIODE
DS5001 LCD
DS5002 LED
J 5001 CONNECTOR
JP5001 WIRE ASSY
Q 5001 IC
Q 5002 TRANSISTOR
Q 5003 IC
Q 5004 TRANSISTOR
Q 5005 IC
Q 5006 TRANSISTOR
Q 5007 IC
Q 5008 IC
Q 5009 TRANSISTOR
Q 5010 IC
Q 5011 IC
Q 5012 IC
Q 5013 IC
R 5001 CHIP RES.
R 5002 CHIP RES.
R 5003 CHIP RES.
R 5004 CHIP RES.
R 5005 CHIP RES.
R 5006 CHIP RES.
R 5007 CHIP RES.
R 5008 CHIP RES.
VALUE V/W TOL.
*** DISPLAY UNIT ***
100pF 50V CH
100pF 50V CH
10pF 50V CH
10pF 50V CH
100pF 50V CH
10pF 50V CH
10pF 50V CH
0.01uF 50V B
100pF 50V CH
10uF 10V
0.01uF 50V B
100pF 50V CH
0.01uF 50V B
0.01uF 50V B
0.01uF 50V B
10uF 10V
0.01uF 50V B
0.01uF 50V B
10uF 25V
100pF 50V CH
100pF 50V CH
100pF 50V CH
680 1/10W 5%
470 1/4W 5%
470 1/4W 5%
5.6k 1/16W 5%
4.7k 1/16W 5%
47k 1/16W 5%
5.6k 1/16W 5%
47k 1/16W 5%
MFR'S DESIG VXSTD P/N
CS1686001
FR003550B
GRM39CH101J50PT K22174235
GRM39CH101J50PT K22174235
GRM39CH100D50PT K22174211
GRM39CH100D50PT K22174211
GRM39CH101J50PT K22174235
GRM39CH100D50PT K22174211
GRM39CH100D50PT K22174211
GRM39B103M50PT K22174823
GRM39CH101J50PT K22174235
TEMSVA1A106M-8R K78100028
GRM39B103M50PT K22174823
GRM39CH101J50PT K22174235
GRM39B103M50PT K22174823
GRM39B103M50PT K22174823
GRM39B103M50PT K22174823
TEMSVA1A106M-8R K78100028
GRM39B103M50PT K22174823
GRM39B103M50PT K22174823
TESVD1E106M12R K78140018
GRM39CH101J50PT K22174235
GRM39CH101J50PT K22174235
GRM39CH101J50PT K22174235
GL8KG21 G2090625
GL8PR21 G2090395
MA143-(TX) G2070536
MA143-(TX) G2070536
MA143-(TX) G2070536
MA143-(TX) G2070536
MA143-(TX) G2070536
MA143-(TX) G2070536
MA143-(TX) G2070536
MA143-(TX) G2070536
HLMF-KL05 G2090692
HLMF-KL05 G2090692
MA143-(TX) G2070536
MA143-(TX) G2070536
MA143-(TX) G2070536
MA143-(TX) G2070536
MA143-(TX) G2070536
TTR3165UPFDCW G6090134
NAA261-B G2090745
12FMZ-BT P1090901
A1367+ T9206797A
DN8657S-T1 G1092688
XN1213-(TX) G3070194
PST596CNR R59-2978 G1092588
XN1213-(TX) G3070194
TC7S04FU TE85R G1091530
DTC144EK T146 G3070033
HD4074829TF R0320 G1093180
NM93C86AM8(TAPING) G1092512
DTC144EK T146 G3070033
TC7W125FU(TE12L) G1092923
TC7W125FU(TE12L) G1092923
TC7W125FU(TE12L) G1092923
NJM78L05UA TE1 G1091325
RMC1/10T 681J J24205681
RMC1/4 471JATP J24245471
RMC1/4 471JATP J24245471
RMC1/16 562JATP J24185562
RMC1/16 472JATP J24185472
RMC1/16 473JATP J24185473
RMC1/16 562JATP J24185562
RMC1/16 473JATP J24185473
Display Unit
Parts List
VERS. LOT. SIDE LAYADR
1-
1- B b2
1- B e1
1- B d1
1- B d1
1- B e1
1- B d1
1- B d1
1- B d2
1- B d2
1- B d2
1- A C1
1- B d2
1- B c2
1- A C1
1- A C1
1- B e1
1- B e1
1- B e2
1- B e2
1- B c2
1- B c2
1- B c2
1- A A1
1- A A1
1- B b2
1- B d1
1- B d1
1- B d1
1- B d1
1- B e1
1- B d1
1- B d1
1- A A1
1- A A1
1- B d2
1- B d2
1- B b2
1- B b2
1- B b2
1- A B1
1-
1- B d2
1- B b1
1- B b1
1- B f1
1- B e1
1- B d1
1- B e1
1- B e1
1- A C1
1- A C1
1- B d2
1- B c1
1- A C1
1- A C2
1- B e1
1- B c1
1- B f1
1- B f1
1- B d1
1- A C1
1- B e1
1- B d1
1- B e1
105
