Vertex Standard VXR-7000 Service Manual page 19

Ref. VTX P/N Description Qty.
U04308001 SEMS SCREW HSM3×8
U30312012 FLAT HEAD SCREW M3×12BSNI
U04408001 SEMS SCREW HSM4×8
U30306012 FLAT HEAD SCREW M3×6BSNI
U30314012 FLAT HEAD SCREW M3×14BSNI
U30308012 FLAT HEAD SCREW M3×8BSNI
U04306002 SEMS SCREW HSM3×6NI 12
Ref. VXSTD P/N Description
S5000182 SCREW JFS-4S-B1WM
U10306007 TRUSS HEAD SCREW M3×6B
U04408001 SEMS SCREW HSM4×8
U04308001 SEMS SCREW HSM3×8
U24306001 TAPTITE SCREW M3×6
U24308001 TAPTITE SCREW M3×8
U23308001 TAPTITE SCREW M3×8
U20406007 BINDING HEAD SCREW M4×6B
U20308002 BINDING HEAD SCREW M3×8NI
U20306001 BINDING HEAD SCREW M3×6
U04306002 SEMS SCREW HSM3×6NI
U24310001 TAPTITE SCREW M3×10
U34306001 TAPTITE SCRWE M3X6
U00305001 PAN HEAD SCREW M3×5
U30308001 FLAT HEAD SCREW M3×8
U04335007 SEMS SCREW HSM3×35B
U52408002 HEX HEAD BOLT M4×8NI
U51416007 HEXA SOCKET BOLT M4×16B
U70004002 PLAIN WASHER FW4NI
U71004002 SPRING LOCK WASHER SW4NI
U72004002 TOOTHED LOCK WASHER OW4NI
U20308001 BINDING HEAD SCREW M3×8
U20304001 BINDING HEAD SCREW M3×4
U20305001 BINDING HEAD SCREW M3X5
U32450001 FLAT HEAD SCREW M2.6X5
Non-designated parts are available only
as part of a designated assembly.
FILTER Unit
5
1
4
9
5
2
S6000384
PCB SPACER (6pcs)
Q7000303 (VTX)
Q7000391 (EXP : CE ON)
Q7000427 (EXP : CE OFF)
POWER SUPPLY ASS'Y
S8001794
SPACER(5pcs)
S8001782
THERMAL CONDUCTOR(4pcs)
S8001784
FITTING(5pcs)
Qty.
2
14
4
2
34
13
1
4
8
6
12
6
2
2
4
RA0180600
4
KNOB (POW)
1
2
RA018270B
1
FRONT PANEL ASS'Y
1
1
3
7
2
2
RA0180500
VOLUME KNOB
S8001786
COVER
S8000030
FITTING
S8001785
HEATSINK
RA0180800
SHIELD CASE COVER (RF)
N4090148
PUSH SWITCH
Display Unit
RA0181500 KEY Unit
RX Unit
PANEL FRAME
SQL Unit
VOL Unit
RA0180700
PUSH KNOB (4pcs)
Exploded View & Miscellaneous Parts (Lot.71-)
S6000366
RA018100A
EDGE HOLDER
SHIELD CASE COVER
S6000366
EDGE HOLDER
CNTL Unit
TX Unit
P1091073
M4090066
CONNECTOR
SPEAKER RA0181200
HOLDER (MJ)
RA0065800
RUBBER HOLDER (SP)
RA0181300
TOP CASE
RA0180900
SHIELD CASE COVER (PA)
Q6000169
TERMINAL STRIP
S5000215
FAN GUARD
P0090811
CONNECTOR
P1091072
CONNECTOR
P9090014
CONNECTOR (2pcs)
M2090032
FAN
PA-2 Unit
CS1861002
Heat sink PA-2 ASSY
RA018000A
CHASSIS
P1090654
CONNECTOR
RA0181400
BOTTOM CASE
R3054370
FOOT (4pcs)
19
