- Page 1 Quick Installation Guide P/N MHM-97409.4 CSI 9420 April 2010 CSI 9420 Wireless Vibration Transmitter Start Step 1: Physical Installation Step 2: Verify Operation Step 3: Communication and Configuration www.mhm.assetweb.com...
-
Page 2: Important Notice
IMPORTANT NOTICE The CSI 9420 and all other wireless devices should be installed only after the 1420 Wireless Gateway has been installed and is functioning properly. Wireless devices should also be powered up in order of proximity from the 1420 Wireless Gateway, beginning with the closest. - Page 3 This Quick Installation Guide applies to both the 2.4 GHz and 900 MHz Wireless HART versions of the CSI 9420. If you are unsure which version the device is, look in the upper right-hand corner of the nameplate, as illustrated in Figure 1 below.
-
Page 4: Step 1: Physical Installation
10...28V DC (24V nominal) power supply to the bottom two screw terminals on the right (see Figure 3). Pull the wiring through the threaded conduit entry. When selecting the power supply, note that each CSI 9420 has a peak current draw of 40 mA when awake and powering sensors. - Page 5 7. Position the antenna such that it is vertical, either straight up or straight down. Figure 2. Remote mounting of the CSI 9420 involves mounting the device away from the equipment to be measured (upper left), connecting a sensor or accelerometers to the equipment and the CSI 9420 (upper...
-
Page 6: Connecting Sensors
April 2010 Connecting Sensors One or two accelerometers can be connected to the CSI 9420. Only one accelerometer with an embedded temperature sensor can be connected to the CSI 9420. Refer to Figure 3 showing the connector labels mentioned below. -
Page 7: Verify Operation
If the LCD is installed and enabled, during normal operation, the LCD displays the measured values at the configured update rate. Every time the CSI 9420 device wakes up to make a measurement it displays these screens and then takes the measurement. Refer to the CSI 9420 User’s Manual for error codes and other LCD messages. - Page 8 To use the 375/475 Field Communicator with the rev 3 CSI 9420, a rev 3 DD (Device Description file) is required. The rev 3 DD for the CSI 9420 is located on the CD that is shipped with the CSI 9420. 375/475 System Software version 3.2 or later is also required.
- Page 9 Key sequences for common configuration tasks are shown in Table 6 for the 2.4 GHz Wireless HART version and Table 7 for the 900 MHz version. Table 6. CSI 9420 2.4 GHz Fast Key Sequence Function Key Sequence...
- Page 10 Quick Installation Guide P/N MHM-97409.4 CSI 9420 April 2010 Table 7. CSI 9420 900 MHz Fast Key Sequence Function Key Sequence Menu Items Device Information 1, 1, 8 Tag, Date, Descriptor, Message, Distributor, Write Protect, Model, Dev ID, Final assbly num, Revision #’s...
- Page 11 Quick Installation Guide P/N MHM-97409.4 CSI 9420 April 2010 Figure 7. 1420 Network Settings...
-
Page 12: Troubleshooting
Device Manager and choose Rebuild and Identify Hierarchy. Prior to joining the CSI 9420 to the wireless network, it is also possible to configure the network settings from AMS Device Manager using a wired HART modem. The drag-and-drop feature in AMS Device Manager allows automated joining of a wireless device to an existing network using a wired HART modem. -
Page 13: Product Certifications
RODUCT ERTIFICATIONS The CSI 9420 has a number of certifications and approvals including CE, FCC, R&TTE, FM, CSA, and ATEX. Please refer to the User’s Manual for a complete list of product certifications. The User’s Manual is included on the CD that ships with the device or it may be downloaded from the web at www.mhm.assetweb.com. - Page 14 Quick Installation Guide P/N MHM-97409.4 CSI 9420 April 2010...
