Chloride Power Protection Active 700 Operating Manual page 27

Active 1000 T and Active 1500 T:
BP-A1000/1500-T:
1. Battery pack connector
2. RJ11 port for battery pack
detection cable
3. Circuit breaker
4. Battery pack connector
Chloride Active
1. SNMP Slot
2. Input circuit breaker
3. Input power connection
4. Not controllable output sockets
5. Controllable outlets (2 groups)
6. USB port
7. RS232 port
8. Fan
9. External battery pack connector
10. RJ11 port for battery pack
detection cable
11. ROO/RPO terminals
12. Earth screw
