Flange Bearing Service - Toro ProCore Processor Service Manual

Flange Bearing Service

8
RIGHT
FRONT
1. Shaft (chopper axle shown)
2. Grease fitting
3. Flange bearing
4. Pulley
The ProCore Processor jack shaft, chopper axle and
brush shaft all use two (2) of the same flange bearings
for support. Removal and installation of these bearings
requires the same procedure.
Chassis
3
11
Light Oil
7
5. Taper lock bushing
6. Lock nut (4 used per bearing)
7. Flat washer (4 used per bearing)
8. Screw (4 used per bearing)
CHOPPER AXLE DRIVE SHOWN
8
2
7
6
10
9
Figure 8
Page 6 - - 12
12
1
Light Oil
2
4
3
6
9. Taper lock bushing
10. Pulley
11. Shaft (jack shaft shown)
12. Idler pulley
ProCore Processor
5
