Raise/Lower Relief Valve Pressure Test

PRESSURE
GAUGE
Hydraulic System
PRESSURE
GAUGE
LIFT RELIEF
MANIFOLD
NOTE: For identification purposes, the hydraulic hose
to lift relief manifold port A is equipped with a cable tie
at the Core Processor quick coupler.
LIFT RELIEF
MANIFOLD
Page 4 - - 18
RAISE
LIFT
CYLINDER
(EXTENDING)
LOWER
LIFT
CYLINDER
(RETRACTING)
Raise and Lower Relief
Valve Pressure Test
Working Pressure
Return
Flow
ProCore Processor
