- Page 1 COH-Tx & COH-Rx HDMI to Optical Transmitter and Receiver Operation Manual COH-Tx & COH-Rx...
-
Page 2: Copyright Notice
Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document. Cypress also makes no commitment to update or to keep current the information contained in this document. -
Page 3: Safety Precautions
Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 4: Table Of Contents
Table of Contents Introduction ……………………..……………………...…..….……. Applications …………………..………………….……....….. Package Contents ………………………...………....… System Requirements ……………..………..………....……. Features …………………………………………..……..…...…… Specifications ………………………………...……..………..…. Operation Controls and Functions ……………...……....…… Front Panel ................Transmitter Side .…………………………………..…...….… Receiver Side ................Rear Panel .…………………………………..……..…...….… Transmitter Side ............... Receiver Side .………………………………….…..…...….… Support Timing Chart .......…..………..…..…..…... -
Page 5: Introduction
HDMI signals at very long distances. Enter the COH-Tx & COH-Rx HDMI to Optical Transmitter and Receiver which uses fiber optic cables to give you a longer transmission distance, up to 500m while also providing you with thinner lighter cables for easy installations. -
Page 6: Features
5. Features HDMI v1.2, HDCP and DVI compliance Long distance transmission up to 10KM or more Thinner and lighter cables for better looking and easier installations Faster data transmission Lower power consumption FPGA-based solution Supports EDID reading and CEC function ... -
Page 7: Specifications
6. Specifications Transmitter Input Port 1 x HDMI Output Port 1 x Fiber Optical Receiver Input Port 1 x Fiber Optical Output Port 1 x HDMI Dimensions (mm) 114(W) x 65(D) x 26(H) Weight(g) Chassis Material Aluminum Silkscreen Color Black Operating Temperature 0˚C ~ 40˚C / 32˚F ~ 104˚F Storage Temperature... -
Page 8: Operation Controls And Functions
7. Operation Controls and Functions 7.1 Front Panel Transmitter Side Receiver Side HDMI OPTICAL OPTICAL HDMI INPUT LINK LINK OUTPUT ERROR ERROR HDMI LINK HDMI LINK ① ② ③ ④ ① ② ③ ④ ① HDMI LINK: This LED will turn blue when the device receives a signal from the source or display. -
Page 9: Support Timing Chart
8. Support Timing Chart Formats Field Rate Picture Aspect Ratio 640x480p 59.94Hz/60Hz 720x480p 59.94Hz/60Hz 720x480p 59.94Hz/60Hz 16:9 1280x720p 59.94Hz/60Hz 16:9 1920x1080i 59.94Hz/60Hz 16:9 720(1440)x480i 59.94Hz/60Hz 720(1440)x480i 59.94Hz/60Hz 16:9 720(1440)x240p 59.94Hz/60Hz 720(1440)x240p 59.94Hz/60Hz 16:9 ... -
Page 10: Connection And Installation
1920x1080p 23.97Hz/24Hz 16:9 1920x1080p 25Hz 16:9 1920x1080p 29.97Hz/30Hz 16:9 2880x480p 59.94Hz/60Hz 2880x480p 59.94Hz/60Hz 16:9 2880x576p 50Hz 2880x576p 50Hz 16:9 1920x1080i (1250 total) 50Hz 16:9 9. Connection and Installation COH-TX COH-RX HDTV/Monitor Blu-ray... -
Page 11: Acronyms
Acronyms Acronym Complete Term... - Page 12 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20100803 MPM-COHRXTX...
