- Page 1 CA-DVI250R DVI over CAT5 Receiver Box Operation Manual CA-DVI250R...
-
Page 2: Revision History
Revision History Version No Date Summary of Change 20090401 Preliminary Release Precaution Failure to follow the precautions described below may cause damage to DVI over CAT 5 Transmitter and Receiver Box and void the warranty. • DO NOT open the case. Doing so will void the warranty. If you find problem with it, please return back to your retailer or seller who will assist you or provide you with solution. -
Page 3: Table Of Contents
Table of Contents 1. Introduction .................. 1 2. Applications ................. 1 3. Contents ..................1 4. System Requirements ..............1 5. Features ..................2 6. Operation Controls and Functions ..........3 6.1 Receiver’s Front Panel ............. 3 6.2 Receiver’s Rear Panel ............. 4 7. Connection and Installation . -
Page 4: Introduction
1. Introduction The DVI Receiver over CAT 5 is device that is used to receive DVI signals. Not only can this amazing piece of equipment receive an HD signal but it can also handle analog and digital audio signals too. Through the use of a DDC cable this device can also support HDCP and CEC. -
Page 5: Features
5. Features • Compatible with HDMI 1.2, HDCP 1.1 and DVI 1.0. • Supports Equalizer, Gain, CTI (Color Transient Improvement) adjustment. • Supports high definition input/output up to 1080P/UXGA. • Easy to install and operate. • Connects CAT 5 to DVI without any signal loss even after transferring 250meters. -
Page 6: Operation Controls And Functions
6. Operation Controls and Functions 6.1 Receiver’s Front Panel VIDEO DC 5V EQUALIZER GAIN 250M 150M 100M CAT5 INPUT ADJUST ① CTI dip switch – To optimize the CTI use the twin switches to set the operating distance. 150 - 250m ↑... -
Page 7: Receiver's Rear Panel
6.2 Receiver’s Rear Panel CAT5 to DVI 250M / RECEIVER DVI-D COAX ① DVI-D OUT – Connect to the DVI/HDMI port of the display using either a DVI or DVI to HDMI cable. ② COAX OUT – Connect to an audio amplifiers/audio devices input using a coaxial cable. -
Page 8: Connection And Installation
7. Connection and Installation DVD Player Co-ax VIDEO (CAT-5 Cable) Cable Cable HDMI to DVI Cable Cable DDC (CAT-5 Cable) VIDEO DVI to CAT 5 / TRANSMITTER DC 5V COAX 250 Meters DVI-D COAX AUDIO CAT5 OUTPUT Transmitter unit Transmitter unit Front Rear VIDEO... -
Page 9: Specifications
8. Specifications Transmitter Input port 1 x DVI-I female port (Accepts DVI-D signals only) 1 x Coaxial 1 x L/R Audio Transmitter Output port 2 x CAT5 RJ 45 8pin Receiver Input port 2 x CAT5 RJ 45 8pin Receiver Output port 1 x DVI-I female port 1 x Coaxial 1 x L/R Audio... - Page 12 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20090402 MPM-CADVI250R...
