Receiving Frame Rear Panel
• USB Connector - Provides a standard interface for USB 2.0 signals.
• DC Power Connector (PWR1) - A standard 4-pin DC power connector is used to ac-
cept DC power.
• Jumper (JP2) - Factory-installed jumper on Pins 2 & 3.
StorCase Technology, Inc.
DC Power
(Power Cable
not shown)
Figure 5: Receiving Frame Motherboard (Rear View)
Jumper
(Factory-Installed)
