Carefully turn the drive/circuit board assembly upside-down (drive is bottom-mounted
into bracket). Install the drive mounting bracket and secure with four (4) M3 screws
(provided) as shown in Figure 9.
M3 Phillips
Flat Hd. Screw
(4 Total)
DE50 for Backup User's Guide - Rev. D00
Front
Figure 9: Drive Mounting Bracket Installation
Circuit
Board
Drive Mounting
Bracket
