5.25” Adapter Bracket

NOTE:

Some DE50 models do not include a 5.25” adapter bracket.

1.68

(42.7mm)

(147.8mm)

Figure A-2: DE50 Adapter Bracket Physical Dimensions

StorCase Technology, Inc.

5.82

(Dimensions are for reference only)

Appendix A - Specifications/Dimensions

0.47

(12.0mm)

2.09

(53.0mm)

DE50 for Backup User's Guide - Rev. D00

3.12

(79.2mm)

5.48

(139.2mm)

0.39

(10.0mm)

5.73

(145.5mm)
