10
11
12
The EVOi.net is equipped with four mounting holes for
installation in one RU (rack unit) space.
Insert the enclosed power cord into the IEC connector to
supply the specified AC power.
The removable fuse protects internal circuits. When
replacing the fuse, be sure to use the same type as speci-
fied.
Two 8-pin RJ-45/Shellnet connectors, labeled
, will provide interlinking to other EVOi.net
units. Functionality will be determined at a later date.
To protect settings from being inadvertently changed, press
this recessed button once to disable
and
parameters. The orange
on the front panel) will turn on to confirm the
lockout. To restore functionality and to change settings,
press this recessed button once again.
13
14
15
Two 3-pin male XLR connectors for right (4B) and left
(3A) connection to auxiliary EVOi.324 loudspeakers using
a pair of XLR signal cables.
For mono operation, press
signals and route the combination to both outputs. The
mono signal level will be 4 dB lower than the stereo level.
Two 3-pin male XLR connectors for right (2B) and left
(1A) connection to main EVOi.324 loudspeakers using a
pair of XLR signal cables.
and
For mono operation, press
signals and route the combination to both outputs. The
mono signal level will be 4 dB lower than the stereo level.
Two 3-pin female XLR connectors for right (B) and left (A)
connection to the EVOi.sys
and to lock their
pair of XLR signal cables.
(under
A 3-pin female XLR connector for connection to the
enclosed measurement microphone using the supplied 100'
XLR signal cable.
16
17
to sum the input
to sum the input
18
10
using a
