At the beginning of or anytime during a system setup, the
hookup configuration of the EVO loudspeaker can be tested
by using the button.
This button is used to control the user audio test mode, i.e.
pressing it will produce 'pink noise' output from each EVO
loudspeaker.
The first press of the button will...
1. Enable the Test Mode.
2. Illuminate the orange
3. Cause the first found EVO loudspeaker to transmit
'Pink Noise'.
4. Flash the relevant Speaker Status Green
indicate the Limpet transmitting.
Successive presses of the
1. Move the 'Pink Noise' to the next EVO loudspeaker.
2. Indicate the 'New Transmitting' EVO loudspeaker by
flashing the relevant Speaker Status Green
LED.
When all attached EVO loudspeakers have been tested, the
next press of the button will exit Test Mode and
extinguish the LED. There is a short delay between
pressing the button for the last time and returning all
speakers to normal operation.
LED.
LED to
button will...
EQ SELECT SETTINGS
MUSIC I
MUSIC II LOCKED EQ SET
SPEECH
MAIN OUT
NEUTRAL TEST
SETUP 1&2
HOLD TO CLEAR MAIN
If the switch is engaged at any time during Test
Mode, Test Mode will immediately end. The
indicator LED will be extinguished and any EVO loud-
speakers will stop transmitting 'Pink Noise'.
AUTO EQ SETTING
EQ SET
AUX OUT
AEQ ON
SETUP 3&4
HOLD TO CLEAR MAIN
