Summary of Contents for Steris VividImage MON-STE19-1MP
- Page 1 ® VividImage Medical Grade LCD Color Monitor OPERATION MANUAL MON-STE19-1MP MON-STE19-1MP...
-
Page 2: Notice For Users
® VividImage Monitor- MON-STE19-1MP: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 3: Table Of Contents
Table of Contents Notice for Users ............................2 FCC Statement ............................2 Declaration of Conformity ........................... 2 TIPS AND SAFETY PRECAUTIONS ......................4 Monitor and Accessory Checklist ....................... 4 Mounting ..............................4 Location ..............................4 Power Cord ..............................4 Manual Scope ............................4 MONITOR SET-UP AND CONNECTIONS ..................... -
Page 4: Tips And Safety Precautions
-This manual is written for use with the Mounting ® - Always follow mounting instructions to avoid VividImage Medical Grade Color Monitor, item # physical injury and/or damage to the monitor. MON-STE19-1MP. Document # Revision Date 4 of 20 82070-274, Revision A 1/16/2009... -
Page 5: Monitor Set-Up And Connections
Monitor Set-Up and Connections Step 1: Unpacking the Carton Included in the carton are the following items: ® 1 VividImage Monitor 1 Power Cord 1 VGA Cable 1 DVI-D Cable 1 Quick Start Guide 1 Operation Manual (this document) If any one of these items is missing, please call Customer Support at (877) 887-1788. Step 2: Mounting the Monitor The monitor can be placed on the included stand or can be mounted to a VESA wall mount kit (not included). -
Page 6: Step 4: Connecting The Power Cord
Step 4: Connecting the Power Cord Plug the appropriate end of the power cord into the 3-pronged interface on the back of the monitor. Plug the opposite end of the cord into an outlet. The Vacation Switch on the back of the monitor must be turned on. The Vacation Switch is a true on/off switch. -
Page 7: User Interface
User Interface The User Interface The user interface consists of five push buttons, which are located on the front lower right of the monitor. The interface is shown in Figure 4 below. Number Button Description Start the OSD feature MENU Exit the OSD controls Exit to the OSD main menu <... -
Page 8: Osd (On Screen Display)
OSD (On Screen Display) OSD Adjustments Power on the Monitor. Press “Menu” button to start the OSD menu. Press “ ” or “ ” button to select the menu items. Press “Enter” button to enter the menu item. Press “ ”... -
Page 9: Osd Menu Function
OSD Menu Function Main Menu Sub-Menu Description Brightness Adjust the brightness of the screen. Contrast Adjust the contrast of the image. Adjust the purity and depth of the red, blue and green of color. Display Menu Saturation Adjust the saturation of the color. Black Level Adjust the black level. -
Page 10: Table 1: Osd Menu Function
H-Position Move the OSD left and right on the screen. V-Position Move the OSD up and down on the screen. Rotation Rotate the OSD. OSD Menu Time Out Adjust OSD display time setting. Language Choose language to display on the screen. All Reset Recall the factory default settings. -
Page 11: Structure Of Osd Menus
Structure of OSD Menus How To Lock 1. Press “Menu” button to start OSD menu. 2. Select “Setup Menu” and press “Enter”. Setup Menu All Reset DVI Select Lock Mode Information Overlapped 3. Select “Lock Mode” and press “Enter” Setup Menu All Reset DVI Select Lock Mode... -
Page 12: Lock Mode
Lock Mode • Off: OSD Menu is not locked. Pressing “Menu” starts the OSD menu and all functions can be adjusted. • Mode 1: OSD Menu is locked and no functions can be adjusted. • Mode 2: OSD Menu is locked except “Brightness”. Pressing “Menu” displays the “Brightness” control menu. -
Page 13: How To Unlock
How to Unlock If setting is in “Mode 1” or “Mode 2” and you want to unlock, hold the “-” button on the user interface until message on the screen displays “OSD Unlocked”. Lock function is then removed. OSD Unlocked Notes: •... - Page 14 2. Mode Item Selection Press “<” button to select the display mode. User Mode DICOM Mode CL Mode BL Mode LB Mode • User Mode: User identifies the standard display operation • DICOM Mode : System sets the DICOM standard operation •...
-
Page 15: Features
Features • The integrated interface ratified by the Digital Display Working Group (DDWG) that allows both digital and analog connectors off of one port. The “I” stands for integration for both digital and analog. The digital portion is DVI based. •... -
Page 16: Monitor Care / Troubleshooting
Monitor Care / Troubleshooting Monitor Care Troubleshooting Always remove the plug from the AC outlet when Please follow these troubleshooting tips prior to cleaning the monitor. contacting customer support. LCD Panel The image is not displayed on the screen - Is the power cord connected properly? Use a mild soap &... -
Page 17: Specifications
Specifications ® VividImage Model # MON-STE19-1MP Inputs: Composite S-Video RS232 For manufacturer to load firmware. No end-user function. Stand Tilt/Swivel Touch Screen Option Cable Cover Resolution 1280 x 1024 Aspect Ratio Brightness 280 cd/m2 Contrast 600 to 1 Viewing Angle (horizontal vertical) &... -
Page 18: Glossary
Glossary Black Level: This adjustment allows the display to be set to discriminate between small differences in dark or near black areas of the image. The adjustment should make a black area of the image (such as a deep shadow where all detail is lost in the image) appear black. The black level is decreased (less black) until a change toward light or grey is perceived in this area, then the adjustment should be increased slightly to restore the dark area to black. -
Page 19: Index
Index Accessory Checklist, 4 Mode, 14 Mode 1, 12 Mode 2, 12 Monitor Care, 16 Mounting, 5 Black Level, 18 Brightness, 18 On Screen Display, 8 OSD, 8, 9, 11, 16 Cable Cover, 5 OSD Display Menu, 8 Care, 16 OSD Menu Function, 10 Clock, 18 Color Temperature, 18... -
Page 20: Contact Customer Support
Contact Customer Support 40 Melville Park Road Melville, NY 11747 (877) 887-1788 is a registered trademark of STERIS Corporation. ® VividImage is a registered trademark of VTS Medical Systems, LLC Printed in USA Document # Revision Date 20 of 20...
