Note: If a separate 'Producer' Talkback unit is required this can be achieved with a simple parallel
physical connection of buttons that both activate the Mixer to Vocal Booth GPI.
Setting Up
1. Click on Studio Add
A New Monitor Studio box appears. Type a suitable name for the Studio, in this case, Vocal Booth and press
the keyboard Enter key to confirm.
The red button indicates that the destination is active.
Note: The Talkback section will be shown at the bottom of the Monitor ! page if any destina-
tions are active in the Talkback page.
2. Notice the two boxes to the right of the name with orange dashes. Click on the left box to drop down the Set
Output Connection menu:
3. choose a suitable physical output to feed the Talkback amplifier/loudspeaker.
Note: If you only have digital outputs then you will need a converter.
4. If you wish to have stereo talkback/foldback repeat steps 2&3 for the right-hand box. Here only the Vocal
Booth is to be fed with Foldback so that is the only stereo destination.
5. Repeat steps 1 to 3 twice to add two more destinations.
6. Label these to suit, in this case, Mix Room and Machine Room.
Monitor Talkback page Destination Output Connection
Monitor : Talkback 11 - 247
