Chapter 4 • Programmer's Guide
Z C C
AP ONFIGURATION OMMANDS
Zap All Global presets & names
Zap individual Global
Zap All Room presets & names
Zap individual Room Preset
Zap All RGB Delay to Ø sec.
Zap all Audio Gains to Ø dB.
UnMute RGB/Audio (All Mutes)
Factory Master Reset
If the switcher receives a command that is invalid or contains invalid parameters, it will return an Error Code response.
The error code response has the format "Exx". Following is a list of possible error code responses.
When a local event takes place, such as a Front Panel operation, the switcher responds by sending an unsolicited
response (RECONFIGxx) to the Host. Use the 2 digit code xx to locate a description of the event below.
RECONFIGØØ = Audio level change
RECONFIGØ2 = Room#1 or room#1's preset name change
RECONFIGØ3 = Room#2 or room#2's preset name change
RECONFIGØ4 = Room#3 or room#3's preset name change
RECONFIGØ5 = Room#4 or room#4's preset name change
RECONFIGØ6 = Room#5 or room#5's preset name change
RECONFIGØ7 = Room#6 or room#6's preset name change
RECONFIGØ8 = Room#7 or room#7's preset name change
RECONFIGØ9 = Room#8 or room#8's preset name change
RECONFIG1Ø = Room#9 or room#9's preset name change
RECONFIG11 = Room#1Ø or room#1Ø's preset name change
RECONFIG12 = Name change for global preset #1-16
RECONFIG13 = Name change for global preset #17-32
RECONFIG14 = Current connection change
RECONFIG17 = Name change for virtual input #1-16
RECONFIG18 = Name change for virtual input #17-32
RECONFIG19 = Name change for virtual input #33-48
RECONFIG2Ø = Name change for virtual input #49-64
RECONFIG21 = Name change for virtual output #1-16
RECONFIG22 = Name change for virtual output #17-32
RECONFIG23 = Name change for virtual output #33-48
RECONFIG24 = Name change for virtual output #49-64
Extron • Matrix 3200/6400 Series • User's Manual
ASCII (H -S )
OST WITCHER
zG
zT
zP
zT *
zD
zA
zZ
zXXX
E C
RROR ODES
Description of Error code
EØ1 Invalid input channel number (too large)
EØ5 Device is off
E1Ø Invalid command
E11 Invalid preset number (too large)
E12 Invalid output number (too large)
E13 Value too large (Gain)
E14 Command not available for matrix configuration
E17 Timeout
E2Ø Invalid BME number
E21 Invalid Room number
E22 Busy
E23 Checksum error
S G U
WITCHER ENERATED NSOLICITED
RESPONSE (S -H
WITCHER OST
ZapG
ZapT
ZapP
ZapT
ZapD
ZapA
ZapZ
ZapXXX
R
ESPONSES
)
4-8
