Sync — sync BME
Input and output types ................ Software configurable for RGBHV or RGBS
Sync connectors ......................... Up to 64 or 32 BNC female (quantity varies with configuration)
Input level ................................... 0.5V to 5V p-p (4V p-p nominal)
Output level ................................ 5V p-p
Gain ........................................... AGC to TTL .............. 4.0V to 5.0V p-p
Input impedance ......................... Inputs 1 - 16 ............. 510 ohms or 75 ohms, switchable
Output impedance ...................... 75 ohms
Horizontal frequency .................. 15 kHz to 150 kHz
Vertical frequency ...................... 30 Hz to 150 Hz
Polarity ....................................... Positive or negative (follows input)
Control/remote — switcher
Serial control port ....................... RS-232 or RS-422, 9-pin female D connector
Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity
Serial control pin configurations ..... 2 = TX, 3 = RX, 5 = GND
System intercommunications ...... 2 RJ11 connectors
Remote keypad control .............. 2 5 mm, 5-pole captive screw connectors
Program control .......................... Extron's control program for Windows®
General
Power ........................................ 100VAC to 240VAC, 50/60 Hz; internal, auto-switchable
Temperature/humidity ................ Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, non-condensing
Rack mount ................................ Yes
Enclosure type ........................... Metal
5U dimensions ........................... 8.75" H x 19.0" W* x 14.0" D
7U dimensions ........................... 12.25" H x 19.0" W* x 14.0" D
Shipping weight .......................... Matrix 6400 Wideband .......... 41 lbs (18.5 kg)
Vibration ..................................... NSTA 1A in carton (National Safe Transit Association)
Approvals ................................... UL, CUL, CE
MTBF ......................................... 30,000 hours
Warranty .................................... 2 years parts and labor
NOTE: Specifications subject to change without notice.
1-9
Chapter 1 • Introduction to the Matrix 3200 & 6400 Wideband Video/Sync Switchers
Inputs 17 - 64 ........... 510 ohms
Extron's Simple Instruction Set™ – SIS™
Matrix 6400 Wideband .......... 105.7 watts at 115VAC, 60 Hz
Matrix 3200 Wideband .......... 48.9 watts at 115VAC, 60 Hz
Operating +32° to +122°F (0° to +50°C) / 10% to 90%, non-condensing
22.2 cm H x 48.3 cm W* x 35.6 cm D
*17.0" (43.18 cm) W excluding rack ears
31.1 cm H x 48.3 cm W* x 35.6 cm D
*17.0" (43.18 cm) W excluding rack ears
Matrix 3200 Wideband .......... 31 lbs (14.0 kg)
Both models: DIM weight ...... 44
