Matrix 3200/6400 Series Part Numbers (continued from previous page)
Extron Part
FPC 1000 (Matrix 6400 Series)
FPC 1000 (Matrix 3200 Series)
MCP 1000M
MCP 1000S
MKP 1000 (Gray)
MKP 1000 (Black)
MKP 1000 (White)
Stereo Audio Input Card (8 Inputs)
Stereo Audio Output Card (8 Outputs)
3200 Series Wideband Input Card (16 Inputs)
6400 Series Wideband Input Card (16 Inputs)
Wideband Output Card (8 Outputs)
Related Part Numbers
Extron Part
Captive Screw Audio Connector
RCA (female) BNC (male) Adapter
SVHS - BNC Adapter
GLI 250 (Ground Loop Isolator, 250 MHz RGBHV)
MKP 1000 User's Manual
FPC 1000 User's Manual
Matrix 6400 Audio User's Manual
Matrix 3200/6400 System Virtualization/Control Software
BNC Cables (Super High Resolution (SHR) BNC Cables)
Extron Part
Bulk Cable
SHR Bulk Cable
Bulk SHR-1, 500'
Bulk SHR-1, 1000'
Bulk SHR-4, 500'
Bulk SHR-5, 500'
BNC SHR crimp connectors, qty. 50
BNC-4 M
Bulk BNC 4-500' HR
Bulk BNC 4-1000' HR
BNC 5 M
Bulk BNC 5-500' HR
Bulk BNC 5-1000' HR
BNC 5 Plenum M
Bulk BNC 5-500' HRP
Bulk BNC 5-1000' HRP
Install Plenum Bulk Cable
Bulk Install Plenum, 500'
Bulk Install Plenum, 1000'
Assorted Connectors
BNC Connectors
BNC M
BNC SHR crimp connectors, qty. 50
BNC Bulkhead connectors, qty. 50 (for custom wall plates)
A-3
Extron SHR BNC cables are Super High Resolution BNC cables. Extron
recommends that when using signals with a scanning frequency of 15-125 kHz
and running distances of 100 feet or more, high resolution BNC cables should be
used to achieve maximum performance.
-HR Bulk Cable
INI
-HR Bulk Cable
INI
-HR B
INI ULK
-HR crimp connectors, qty. 50
INI
Appendix A • Reference Information
