INSTALLING AND USING THE DEVICE
5. To have the device enter sleep mode, set DTR to inactive (off) on the RS-232 interface. The clear to send
(CTS) signal is off when the device is in sleep mode.

USB Cable Recommendations

If your device has a USB connector, to avoid enumeration or power issues:
■ Use a high speed USB cable that is as short as possible.
■ Use a well shielded cable with at least 24 AWG wire pair for power/ground and 28 AWG wire pair for data
lines.
■
If possible, use a USB port that connects directly to the motherboard rather than a USB port with added
cabling inside the computer chassis.
■ Use USB 3.0 ports if available. These ports are typically rated for more current.
■
You can re-order the USB cable through Multi-Tech. The part number is CA-USB-A-MINI-B-3

Mounting Device to Flat Surface

1. Locate the groove on the bottom of the device.
2. Slide the mounting rod through the groove.
3. To secure the rod to the desired surface, place and tighten two screws in the holes on either end of the
mounting rod. The dimensions illustration in this guide shows the mounting rod, as well as the
dimensions for placement of the screws.
16
®
MultiConnect Cell User Guide
