5. To have the device enter sleep mode, set DTR to inactive (off) on the RS-232 interface. The clear to send
(CTS) signal is off when the device is in sleep mode.

USB Cable Recommendations

If your device has a USB connector, to avoid enumeration or power issues:
■ Use a high speed USB cable that is as short as possible.
■ Use a well shielded cable with at least 24 AWG wire pair for power/ground and 28 AWG wire pair for data
lines.
■
If possible, use a USB port that connects directly to the motherboard rather than a USB port with added
cabling inside the computer chassis.
■ Use USB 3.0 ports if available. These ports are typically rated for more current.
■
You can re-order the USB cable through Multi-Tech. The part number is CA-USB-A-MINI-B-3

Installing a SIM Card

This model requires a SIM card, which is supplied by your service provider. To install the SIM card:
1. Locate the SIM card slot on the side of the modem. The slot is labeled SIM.
2. Slide the SIM card into the SIM card slot with the contact side facing down as shown. When the SIM card
is installed, it locks into place.

Removing a SIM Card

To remove the SIM card, push the SIM card in. It ejects itself from the device.

Mounting Device to Flat Surface

1. Locate the groove on the bottom of the device.
2. Slide the mounting rod through the groove.
®
