- Page 1 SSW-321-X-ISSUE 4.0 SERVICE MANUAL MODEL SSW-321-X STAINLESS STEEL WALL TELEPHONE Serving the Telephone Industry Since 1930 Communication Equipment 519 W South Park Street & Engineering Company Okeechobee, FL 34972 Voice: 863-357-0798 Fax: 863-357-0006...
-
Page 2: Important Information
ISSUE 4.0 IMPORTANT INFORMATION CUSTOMER Please fill in before you continue. The following information is necessary when calling CEECO for assistance. MODEL NUMBER MODEL SSW-321-X STAINLESS STEEL WALL TELEPHONE. SERIAL NUMBER DATE MANUFACTURED LOCATION INSTALLED For us to better serve you, please have this information available when calling for technical support. -
Page 3: Table Of Contents
RECOMMENDED TOOLS AND TEST EQUIPMENT ........4 INSTALLATION NOTES AND ASSEMBLY INSTRUCTIONS ..... 5 TESTING ......................... 6 TROUBLESHOOTING GUIDE ................6 SPECIFICATIONS....................7 10.0 FCC NOTICE......................9 11.0 REPAIR AND RETURN INFORMATION ............10 12.0 WARRANTY POLICY ..................11 CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 4: Introduction
GENERAL DESCRIPTION The CEECO Model SSW 321-X is a Stainless Steel Telephone designed for special applications where a durable telephone instrument must be sturdy and attractive. The SSW 321-X will accept incoming calls only. The user cannot initiate a call. Please note, however, that external automatic dialing equipment could be used in conjunction with this phone, which would allow it to automatically dial a number when the handset is lifted. -
Page 5: Installation Notes And Assembly Instructions
Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the network interface. Use caution when installing or modifying telephone lines. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 6: Testing
RJ11C CONNECTOR NETWORK HANDSET HOOKSWITCH ASSEMBLY PROBLEM: DIAL TONE IS DISTORTED POSSIBLE CAUSE: NETWORK HANDSET PROBLEM: TRANSMITTER DOES NOT TURN ON POSSIBLE CAUSE: HANDSET NETWORK PROBLEM: RINGER DOES NOT OPERATE POSSIBLE CAUSE: RINGER NETWORK CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 7: Specifications
5" Wide x 10 3/4" High x 5 1/2" Deep (Handset On Hook) MOUNTING: Vertical Surface Mount WEIGHT: 6 lbs. FCC REGISTRATION: BW88T7-68413-TE-T UL LISTED NO.: 6OF5 RINGER EQUIVALENCY: 0.4A TYPE JACK: RJ11C CEECO Communication Equipment & Engineering Company PROPRIETARY... - Page 8 Hookswitch & Cradle assembly 321-012 Stainless Steel Housing 321-017 Stainless Steel Backplate 301-570 Microswitch 321-016 1/4"x 20"x 3/4" Security Screw 301-018 Modular cord 301-054 Modular jack ACCESSORIES: 301-037 Security tool, 1/8" button head CEECO Communication Equipment & Engineering Company PROPRIETARY...
-
Page 9: Fcc Notice
FCC registration number and ringer equivalence number. These numbers are listed in Section 8.0. The FCC further requires that you notify your local telephone company when permanently disconnecting this telephone. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 10: Repair And Return Information
11.3 NON-WARRANTY REPAIR CEECO will repair equipment out of warranty for a set charge plus parts. The customer must pay the shipping costs both directions. 11.4 RETURN FOR CREDIT Material may be returned for credit only with prior approval. Material authorized for return is subject to a 20% restocking charge based on the manufacturers list price. -
Page 11: Warranty Policy
PRINTED CIRCUIT BOARDS Printed circuit boards should not be field-repaired. If a unit is found to be faulty, replace it with another unit and return the faulty unit to CEECO for repair. Modifications by anyone other than CEECO will void the warranty.
