SMART Notebook SE User Manual page 77

To change an object's fill
to a pattern
To change an object's fill
to an image
To change an
object's line style
To change an
object's animation
69 | CH A P T E R 7 – E DI T I NG A N D E R A S I N G O B J E C T S
1. Select the object.
2. If the Properties tab isn't visible, click Properties
3. Click Fill Effects.
4. Select Pattern Fill.
5. Select a pattern.
6. Click Foreground Color, select a color in the palette, and then click OK.
7. Click Background Color, select a color in the palette, and then click OK.
1. Select the object.
2. If the Properties tab isn't visible, click Properties
3. Click Fill Effects.
4. Select Image Fill.
5. Click Browse.
The Insert Image File dialog box appears.
6. Browse to, and select, the image you want to use, and then click Open.
1. Select the object.
2. If the Properties tab isn't visible, click Properties
3. Click Fill Effects.
4. Click Line Style.
5. Select a color, thickness and style for the line.
1. Select the object.
2. If the Properties tab isn't visible, click Properties
3. Click Fill Effects.
4. Click Object Animation.
5. Select options in the Type, Direction, Speed, Occurs and Repeats lists.
99-00965-20 A0
.
.
.
.
