Section 4. Programming Reference
Fonts U, S, M, OA, OB, XU, XS & XM

Command Structure

Font XU: <ESC>XU
Font XS: <ESC>XS
Font XM: <ESC>XM
Font OA: <ESC>OA
Example:
Placement:
Default:
Command Function
To print text images on a label. These are eight of the built-in fonts available on the
printer. All matrices include descenders.
NON-PROPORTIONAL
U 5W x 9H dot matrix
S 8W x 15H dot matrix
M 13W x 20H dot matrix
OA OCR-A font 15W x 22H dot matrix
OB OCR-B font 20W x 24H dot matrix
(1) These fonts will be printed with proportional spacing only if preceded by an
<ESC>PS command.
Printer Input
<ESC>A<ESC>PS
<ESC>H0001<ESC>V0100<ESC>L0202<ESC>XUSATO
<ESC>H0001<ESC>V0175<ESC>L0202<ESC>XSSATO
<ESC>H0001<ESC>V0250<ESC>L0202<ESC>XMSATO
<ESC>H0001<ESC>V0325<ESC>L0101<ESC>OASATO
<ESC>H0001<ESC>V0400<ESC>L0101<ESC>OBSATO
<ESC>H0300<ESC>V0100<ESC>L0202<ESC>USATO
<ESC>H0300<ESC>V0175<ESC>L0202<ESC>SSATO
<ESC>H0300<ESC>V0250<ESC>L0202<ESC>MSATO
<ESC>Q1<ESC>Z
Page 4-36
SATO M-5900RV Operator and Technical Reference Manual
Font U: <ESC>U
Font S: <ESC>S
Font M: <ESC>M
Font OB: <ESC>OB
See above
Preceding the data to be printed
None
PROPORTIONAL
XU 5W x 9H dot matrix
XS 17W x 17H dot matrix
XM 24W x 24H dot matrix
(1)
PN 9001081
Rev. C
