GE Profile DPVH890EJ Technical Service Manual page 9
Dryer with steam
Hide thumbs
Also See for Profile DPVH890EJ:
- Dimensions and installation information (4 pages) ,
- Owner's manual and installation instructions (156 pages) ,
- Installation information (4 pages)
Table of Contents
Advertisement
Gas Model
Steam Generator
Steam Interlock Relay
Vapor Shield
Power Board
Water Fill Timer
High Limit Thermostat
Inlet Safety Thermostat
Inlet Control Thermistor
Water Valve
®
Rack Dry Calrod
Element
(inside combustion chamber)
Drum Motor
Dual Idler Pully
Outlet Control
Backup Thermostat
Burner Assembly
Blower Motor
(behind frame)
Blower Wheel
Rack Dry Thermostat (behind frame)
Outlet Control Thermistor (behind frame)
– 9 –
