Display Board

The display board is mounted on the underside of
the plastic housing that holds the control board
assembly. The display board snaps onto the plastic
housing via 2 plastic tabs.
To remove the display board:
Caution: To avoid marring the control panel, place
the panel face down on a protective surface.
1. Remove the control and top panels. (See
and )
Panel Top Panel.
2. Remove the 5 Phillips-head screws that attach
the control board plastic housing to the control
panel. Remove the housing.
3. Turn the plastic housing over to expose the
display board.
Display Board
4. Remove the wire harness.
5. Release the display board from the 2 plastic
tabs that attach the display board to the plastic
housing.
Tab
Control
Tab
– 34 –
