SECTION 3: SPECIFICATIONS
Picture Tube
Dot Pitch
Misconvergence
Brightness
Input Signal
Input Signal
Input Connectors
Input Connectors
Synchronization
Video Bandwidth
Display Size
Power Supply
Power Consumption
Environmental
Considerations
14" & 15" Slow Scan Series User Guide

3.1 Technical Specifications

14 inches(VT14A-x),
15 inches(VT15A-x) medium-short persistence phosphor.
Anti-glare, Anti-reflection
0.28mm; Black Matrix
Center 0.3mm; Corner 0.4mm (maximum)
60FL Peak White; 30FL Flat Field
Analog Composite Video: 1.0V p-p/75 ohm, White Positive, Sync Negative.
Separate Analog Video: 0.7V p-p/75 ohm, White Positive.
Separate Sync: TTL Level Composite or Separate H&V, Positive/Negative Polarity
Analog Video: 3/4/5 BNC; HD15; Switchable
Digital Video: DB9
Power: IEC Outlet.
Horizontal: 15 to 48kHz (Automatically)
Vertical: 50 to 120Hz (Automatically)
80MHz
Horizontal: 9.84" (250mm) to overscan (Adjustable)
Vertical: 7.28" (185mm) to overscan (Adjustable)
90-264VAC Universal, 60/50Hz (Automatically)
100 Watts typical
< 20 Watts maximum - Standby/Suspend modes
Operating Temperature: 0ºC to 50ºC @ Humidity: 20% to 80%NC
Storage Temperature: -20ºC to 60ºC @ Humidity: 10% to 90%NC
13
150-002
