Section 3: Pin Assignments
Sync. Type
Pin No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
14" & 15" Slow Scan Series User Guide
15-Pin Connector
(Figure 1)
Separate
Red
Green
Blue
GND
DDC Return
GND-R
GND-G
GND-B
Reserved
GND
GND
DDC Data
H-Sync.
V-Sync.
DDC Clock
Sync. Type
Pin No. CGA
1 GND
2 GND
3
4 Green
5 Blue
6 Intensity
7 Reserved
8 H-Sync
9 V-Sync
Figure 1: Female Type
1
5
6
10
11
15
6
DB9 Connector
(Figure 2)
EGA
GND
Sec. Red
Red Red
Green
Blue
Sec. Green/Intensity
Sec. Blue
H-Sync
V-Sync
Figure 2: Female Type
9
1
