3.2.2 Loading External Media

1. Open the printer's top cover and separate the media holders to fit the media width.
2. Press down the media holder lock switch to fix the media holder.
3. Feeds the media through the rear external label entrance chute. And place the paper, printing
side face up, through the media guides, media sensor and place the label leading edge onto
the platen roller.
Rear external
label entrance
4. Close the top cover gently.
5. Use "Diagnostic Tool" to set the media sensor type and calibrate the selected sensor. (Start
the "Diagnostic tool"
button)
Note: Please calibrate the gap/black mark sensor when changing media.
Select the "Printer Configuration" tab
8
Click the "Calibrate Sensor"
