Car Solutions Video Interface Manual

For volvo s60; volvo xc 60
Hide thumbs Also See for Video Interface:
Table of Contents

Advertisement

Quick Links

Download this manual
Video Interface
for
Volvo S60, XC 60
Manual
support@car-solutions.com
www.car-solutions.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Video Interface and is the answer not in the manual?

Questions and answers

Related Manuals for Car Solutions Video Interface

Summary of Contents for Car Solutions Video Interface

  • Page 1 Video Interface Volvo S60, XC 60 Manual support@car-solutions.com www.car-solutions.com...
  • Page 2 Warning / Caution  When installing the main unit, do not remove or alter existing vehicle fasteners, including nuts, bolts, screw, clips, and fittings. Never detach, move or alter existing vehicle wiring, including electrical grounds and straps. Alteration of existing vehicle Warning components may make vehicle unsafe to operate.

  • Page 3: Table Of Contents

    Table of Contents 1. Specifications 1.1 Main Specifications 1.2 Functions 1.3 System Diagram 1.4 Components 1.5 Exterior 2. Installation 2.1 Installation Diagram 2.2 Installation 2.3 CAN wire Installation 3. Settings 3.1 DIP Switch 3.2 Remote Control 3.3.1 Parking guidelines/3D PDC 3.3.2 PIP(picture in picture) 3.3.3 Factory Mode -IMAGE, PARK 3.3.4 Factory Mode –...

  • Page 4: Specifications

    1. Specifications 1.1 Main Specifications 1. Car Compatibility Volvo S60, XC 60 2015 year 2. Components Interface* 1EA 3. MULTIMEDIA INTERFACE input specification 3 * A/V input (video external input) 1 * CVBS(Rear Camera) input 2 * Analog RGB input (Navigation system, HDMI) 1 * LCD input (Car system input) 4.

  • Page 5: Functions

    1. Specifications 1.2 Functions 1. Dynamic PAS(Parking assistance system)+3D PDC(Parking distance control) - moving parking line according movement of steering wheel - Front / Rear car distance sensor display in external mode 2. Support PIP display – showing sources at the same time (Picture in Picture) support@car-solutions.com www.car-solutions.com...

  • Page 6: System Diagram

    1. Specifications 1.3 System Diagram Switch for source toggle Remote control OEM Button (Can Signal) NAVIGATION Input (Analog RGB) HDMI Input (Analog RGB-2) DISPLAY Car Installation A/V 1 OEM LCD VIDEO MUX A/V 2 VIDEO CIRCUIT A/V 3 CVBS (Rear camera) Car Screen Input (CAR MAIN BOARD) POWER...

  • Page 7: Components

    1. Specifications 1.4 Components TOUCH IN cable * 1ea (HTOUCH0009) LVDS IN/OUT cable * 1ea (HLCDCA0028) MODE cable * 1ea (HARETC0001) IR cable * 1ea (HIRCAB0002) REAR CAMERA TOUCH OUT cable * 1ea POWER cable * 1ea (HTOUCH0004) (HARETC0002) RGB_IN cable(9P) * 1ea AV cable * 1ea (HRGBCA0013) support@car-solutions.com...

  • Page 8: Exterior

    1. Specifications 1.5 Exterior Dimension ⑪ ⑫ ⑩ ⑨ ⑬ Width 164mm Length 91mm Height 19mm ① MODE ② IR ③ POWER ④ TOUCH OUT ⑤ REAR ⑥ RGB-IN(HDMI) ⑦ RGB-IN(NAVI) ⑧ AV/INOUT ⑨ LVDS IN ⑩ T/S-IN ① ② ③ ④ ⑤ ⑥...

  • Page 9: Installation Diagram

    2. Installation 2.1 Installation Diagram OEM LCD Cable MONITOR COMMAND Supplied LCD OUT Supplied LCD IN CAN-H CAN-L REAR-C ※ Pl ease connect AC C cabl e t o B+ cabl e support@car-solutions.com www.car-solutions.com...

  • Page 10: Settings

    3. Settings 3.1 DIP Switch ※ Example DIP S/W usage - Use input mode : A/V2, A/V3 - Use original navigation - External rear camera ▷DIP S/W : 1  ON (hide INPUT MODE) ▷DIP S/W : 2,3  OFF (A/V1,2 display) ▷DIP S/W : 4 ...

  • Page 11: Remote Control

    3. Settings 3.2 Remote Control Funct i on Funct i on Unavailable PO W ER A/V 1~2 Mode : Remote control UI Display PI P HDMI, A/V 3 Mode : Mode switching UI Display Activating OSD menu M ENU Making a selection, changing image display Moving upward ▲...
  • Page 12 3. Settings 3.3.1 Rear parking guidelines < Rear camera full screen > < PIP screen > ☞ C hange t he si ze of i m age : Pr ess C AM but t on i n Rear m ode. ☞...

  • Page 13: Pip(Picture In Picture)

    3. Settings 3.3.2 PIP(Picture in Picture) < Before Approaching objects> < After Approaching objects> - PI P i m age w i l l be show n as above. (Car without Front sensor : Not applicable) support@car-solutions.com -12- www.car-solutions.com...

  • Page 14: Factory Mode-Image, Park

    3. Settings 3. Settings 3.3.3 FACTORY MODE-IMAGE, PARK FACTORY mode – Press button 2 seconds long on the remote control. ◀  PARK  IMAGE PAS TYPE : Selecting Type of parking guide line Adjust navigation position and size - NOT USED : Not use Parking guide line - PAS ON : Selecting Dynamic Parking guide H-POSITION : Move display horizontally line...

  • Page 15: Factory Mode - Util

    3. Settings 3.3.4 FACTORY MODE-UTIL1 FACTORY mode – Press button 2 seconds long on the remote control. ◀  Setup for car model  Setup for navigation HDMI SKIP HDMI SKIP HDMI SKIP HDMI SKIP  UTIL1 - CAR MODEL ...
  • Page 16 3. Settings 3.3.4 FACTORY MODE-UTIL1 FACTORY mode – Press button 2 seconds long on the remote control. ◀ HDMI SKIP HDMI SKIP HDMI SKIP  UTIL1 – AVOUT SELECT  UTIL1 – HDMI SKIP Selecting background sound Selecting whether to use After HDMI function or not returning navigation or original...
  • Page 17 3. Settings 3.3.5 FACTORY MODE-UTIL2 FACTORY mode – Press button 2 seconds long on the remote control. ◀  UTIL2 - I_DRV REMOTE  UTIL2 - I_DRV CONTROL Choose DTV and DVD model Selecting whether to use I_DRV to be control I_DRV function function or not LI-1DISC ON / OFF...
  • Page 18 3. Settings 3.3.5 FACTORY MODE-UTIL2 FACTORY mode – Press button 2 seconds long on the remote control. ◀  UTIL2 – IR MEMORY ② Picture above shows DVD ① First of all, press button on ◀ remote control button value remote controller 2 seconds input, select menu you want long or press...
  • Page 19 3. Settings 3.3.5 FACTORY MODE-UTIL2 FACTORY mode – Press button 2 seconds long on the remote control. ◀  UTI L2 – I R M EM O RY ③ After register, select “SRC” button Instruction> continued… in OSD menu. Then you can see c.

  • Page 20: Factory Mode-Info

    3. Settings 3.3.6 FACTORY MODE-INFO FACTORY mode – Press button 2 seconds long on the remote control. ◀  I NFO C heck m ai n ver si on and Tr i p ver si on support@car-solutions.com -19- www.car-solutions.com...
  • Page 21 3. Settings 3.3.7 OSD (On Screen Display) / Analog RGB Mode  OSD  IMAGE *LANGUAGE : Set OSD language * BRIGHTNESS (only support English and Chinese) * CONTRAST * TRANS : Adjust OSD transparency * SHARPNESS *H-POSITION : Move OSD horizontally * V-POSITION : Move OSD vertically ...
  • Page 22 3. Settings 3.3.8 OSD (On Screen Display) / Video Mode  OSD  IMAGE * LANGUAGE : Set OSD language * BRIGHTNESS (only support English and Chinese) * CONTRAST * TRANS : Adjust OSD transparency * SATURATION * H_POSITION : Move OSD horizontally * HUE * V_POSITION : Move OSD vertically * SHARPNESS...

  • Page 23: Trouble Shooting

    4. Trouble Shooting Q. I cannot change mode A. Check connection of Ground cable and IR Cable. Check LED lamp is on, if not check connection of POWER cable. Q. All I got on the screen is black. A. .Check second LED lamp of the interface is on, if not, check A/V sources connected are working well.
