SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
PELLET STOVE
Milan

Fireplace Insert

OWNER'S MANUAL
Contact your building or fire officials about restrictions and installation
inspection requirements in your area.
PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND
USE OF THIS PELLET BURNING ROOM HEATER. FAILURE TO FOLLOW
THESE INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE,
BODILY INJURY, OR EVEN DEATH.
50-1718

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Milan and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Enviro Milan

Summary of Contents for Enviro Milan

  • Page 1: Fireplace Insert

    SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE PELLET STOVE Milan Fireplace Insert OWNER’S MANUAL Contact your building or fire officials about restrictions and installation inspection requirements in your area.

  • Page 2: Table Of Contents

    Table of Contents Introduction......................3 Rating Label Location..................3 Pellet Quality....................3 Safety Warnings & Recommendations................4 Operating Instructions....................6 Dimensions....................6 Stove Controls....................7 Operating Your Pellet Stove................7 Turning Your Pellet Stove Off................8 Automatic Safety Features................8 Slider/Damper Setting..................8 Routine Cleaning and Maintenance................10 Warranty.........................13 Installation Data Sheet.....................16...

  • Page 3: Introduction

    UALITY Pellet quality is important, please read the following: Your Enviro pellet stove has been designed to burn 1⁄4” (6mm) dia wood pellets only. DO NOT use this appliance as an incinerator. DO NOT use unsuitable and non recommended fuels, including liquid fuels as this will void any warranties stated in this manual.

  • Page 4: Safety Warnings & Recommendations

    To prevent the possibility of a fire, ensure that the appliance is properly installed by adhering to the installation instructions. An Enviro dealer will be happy to assist you in obtaining information with regards to your local building codes and installation restrictions.
  • Page 5 If this power cord should become damaged, a replacement power cord must be purchased from the manufacturer or a qualified Enviro dealer. Be careful that the electrical cord is not trapped under the appliance and that it is clear of any hot surfaces or sharp edges. This unit’s maximum power requirement is 500 watts.

  • Page 6: Operating Instructions

    " (510mm) " (383mm) " (226mm) 44" (1118mm) " (770mm) " " (785mm) (382mm) 2" (51mm) 30" (762mm) " (500mm) " (756mm) Figure 1: Milan Dimensions. " (641mm) " (812mm) 44" (1118mm) Figure 2: Dimensions of Milan with Optional Skirt.

  • Page 7: Stove Controls

    Operating Instructions TOVE ONTROLS 1. ON/OFF BUTTON: Used to turn the unit ON and OFF. 2. AUGER PULSE LIGHT: This light will flash in conjunction with C-11370 the auger. 3. HEAT OUTPUT INDICATOR: Shows the present heat output setting. 4. HEAT LEVEL ADJUSTMENT: When pressed, will change the heat setting of the unit from low to high.

  • Page 8: Turning Your Pellet Stove Off

    Operating Instructions THERMOSTAT / SWITCH MODE: INITIAL START-UP: See above OPERATION - HI / LOW mode: When the thermostat contacts are closed the stove settings are adjustable as per Manual Mode (see above). When the thermostat contacts open, the circuit board will take control of the settings.
  • Page 9 Operating Instructions • A tall, lazy flame with dark orange tips requires more air – Push Right • A short, brisk flame, like a blowtorch, has too much air – Push Left • If the flame is in the middle of these two characteristics with a bright yellow/orange, active flame with no black tips then the air is set for proper operation.

  • Page 10: Routine Cleaning And Maintenance

    Routine Cleaning and Maintenance The following list of components should be inspected and maintained routinely to ensure that the appliance is operating at its optimum and giving you excellent heat value: 2-3 Days / Weekly Semi-annually or 2 Tons of Fuel TOOLS REQUIRED TO CLEAN UNIT Burn Pot and Liner Fresh Air Intake...
  • Page 11 ASH PAN AND DOOR GASKETS (weekly) After extended use the gasketing may come loose. To repair this, glue the gasketing on using high- temperature fiberglass gasket glue available from your local ENVIRO dealer. This is important to maintain an airtight assembly.
  • Page 12 All surfaces should be brushed off periodically. REPLACING DOOR GLASS It is recommended that your ENVIRO dealer replace the glass if broken. The door glass is made of high temperature PYRO CERAMIC 5 mm thick. The panel is 18.5 x 13.5 inches (470 mm x 343 mm) and must be replaced with (PART # 50-1400).

  • Page 13: Warranty

    Industries, our commitment to the highest level of quality and customer service is the most important thing we do. Each Enviro stove is built on a tradition of using only the finest materials and is backed by our Exclusive Lifetime Limited Warranty to the original purchaser. With Enviro, you’re not just buying a stove, you’re buying a company with years of unequalled performance and quality.
  • Page 14 Limited Warranty on this stove. If unsure as to the extent of this Limited Warranty, contact your authorized Enviro dealer before installation. 10. Sherwood Industries Ltd. will not be responsible for inadequate performance caused by environmental conditions.
  • Page 15 If the stove is used for commercial purposes, it is excluded from the Limited Warranty. 24. No dealer, distributor, or similar person has the authority to represent or warrant Enviro products beyond the terms contained within the Limited Warranty. Sherwood Industries Ltd. assumes no liability for such warranties or representations.

  • Page 16: Installation Data Sheet

    Installation Data Sheet The following information must be recorded by the installer for warranty purposes and future reference. NAME OF OWNER: NAME OF DEALER: _________________________________________ _________________________________________ ADDRESS: ADDRESS: _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ PHONE:___________________________________ PHONE:___________________________________ MODEL:___________________________________ NAME OF INSTALLER: SERIAL NUMBER:___________________________ _________________________________________ DATE OF PURCHASE: _____________...
