SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
PELLET STOVE
Milan
Fireplace Insert
OWNER'S MANUAL
Contact your building or fire officials about restrictions and installation
inspection requirements in your area.
PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND
USE OF THIS PELLET BURNING ROOM HEATER. FAILURE TO FOLLOW
THESE INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE,
BODILY INJURY, OR EVEN DEATH.
50-1718
Version Française: www.enviro.com/fr.html
Advertisement
Table of Contents
Related Manuals for Enviro Milan
Summary of Contents for Enviro Milan
-
Page 1: Fireplace Insert
Contact your building or fire officials about restrictions and installation inspection requirements in your area. PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS PELLET BURNING ROOM HEATER. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY, OR EVEN DEATH. 50-1718 Version Française: www.enviro.com/fr.html... -
Page 2: Table Of Contents
Table of Contents Introduction......................3 Rating Label Location..................3 Pellet Quality....................3 Safety Warnings & Recommendations................4 Specifications....................6 Dimensions....................6 Operating Instructions....................7 Control Board Functions..................7 Operating Your Pellet Stove................7 Turning Your Pellet Stove Off................8 Guidelines For Fine-Tuning For Fuel Quality............8 Slider/Damper Setting..................9 Automatic Safety Features................9 Routine Cleaning and Maintenance................10 Warranty.........................13 Installation Data Sheet.....................14... -
Page 3: Introduction
Pellet quality is important, please read the following: Your Enviro pellet stove has been designed to burn ¼” (6mm) dia wood pellets only. DO NOT use this appliance as an incinerator. DO NOT use unsuitable and non recommended fuels, including liquid fuels as this will void any warranties stated in this manual. -
Page 4: Safety Warnings & Recommendations
To prevent the possibility of a fire, ensure that the appliance is properly installed by adhering to the installation instructions. An Enviro dealer will be happy to assist you in obtaining information with regards to your local building codes and installation restrictions. - Page 5 If this power cord should become damaged, a replacement power cord must be purchased from the manufacturer or a qualified Enviro dealer. Be careful that the electrical cord is not trapped under the appliance and that it is clear of any hot surfaces or sharp edges. This unit’s maximum power requirement is 500 watts.
-
Page 6: Specifications
" (510mm) " (383mm) " (226mm) 44" (1118mm) " (770mm) " " (785mm) (382mm) 2" (51mm) 30" (762mm) " (500mm) " (756mm) Figure 1: Milan Dimensions. " (641mm) " (812mm) 44" (1118mm) Figure 2: Dimensions of Milan with Optional Skirt. -
Page 7: Operating Instructions
Operating Instructions ontRoL oaRd unctionS 1. THERMOSTAT SWITCH: Used to set the unit’s controls to one of three mode settings; manual, high/low, or auto/off. 2. FEED RATE TRIM BUTTON: Used to change the feed rate trims in ¼ second increments for all feed settings. When this button is pressed, all the light will light up on the Heat Output Indicator except for the one that shows the current setting;... -
Page 8: Turning Your Pellet Stove Off
Operating Instructions HIGH/LOW MODE: (Requires a thermostat) INITIAL START-UP: See manual mode above. AUTO/OFF AUTO/OFF OPERATION: When the thermostat calls for heat (contacts are closed) HIGH HIGH the stove settings are adjustable as per Manual Mode. When the /LOW /LOW thermostat contacts open, the HEAT LEVEL and Fans will drop down to MANUAL MANUAL... -
Page 9: Slider/Damper Setting
Operating Instructions LideR amPeR etting This is used to regulate the airflow through the pellet stove. THE SLIDER / DAMPER MUST BE SET AT TIME OF INSTALLATION. A Qualified Service Technician or Installer must set the Slider Damper. • If the fire should happen to go out and the heat output indicator has been set on the lowest setting, the Slider Damper should be moved to the left slightly, lessen the air flow into the firebox. -
Page 10: Routine Cleaning And Maintenance
Routine Cleaning and Maintenance The following list of components should be inspected and maintained routinely to ensure that the appliance is operating at its optimum and giving you excellent heat value: 2-3 Days / Weekly Semi-annually or 2 Tons of Fuel TOOLS REQUIRED TO CLEAN UNIT Burn Pot and Liner Fresh Air Intake... - Page 11 ASH PAN AND DOOR GASKETS (weekly) After extended use the gasketing may come loose. To repair this, glue the gasketing on using high- temperature fiberglass gasket glue available from your local ENVIRO dealer. This is important to maintain an airtight assembly.
-
Page 12: Warranty
All surfaces should be brushed off periodically. REPLACING DOOR GLASS It is recommended that your ENVIRO dealer replace the glass if broken. The door glass is made of high temperature PYRO CERAMIC 5 mm thick. The panel is 18.5 x 13.5 inches (470 mm x 343 mm) and must be replaced with (PART # 50-1400). -
Page 14: Installation Data Sheet
SERIAL NUMBER:___________________________ _________________________________________ DATE OF PURCHASE: _____________ (dd/mm/yyyy) DATE OF INSTALLATION:___________ ADDRESS: (dd/mm/yyyy) MAGNEHELIC AT INSTALL:___________________ _________________________________________ _________________________________________ INSTALLER’S SIGNATURE: _________________________________________ _________________________________________ PHONE:___________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.enviro.com March 6, 2013 C-13849...
