SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
PELLET STOVE
M-55-FS
OWNER'S MANUAL
PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION
AND USE OF THIS PELLET-BURNING ROOM HEATER. FAILURE
TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN
PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
Contact your building or fire officials about restrictions and installation
inspection requirements in your area.
50-2061
Advertisement
Table of Contents
Related Manuals for Enviro M-55-FS
Summary of Contents for Enviro M-55-FS
- Page 1 SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE PELLET STOVE M-55-FS OWNER’S MANUAL PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS PELLET-BURNING ROOM HEATER. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
-
Page 2: Table Of Contents
Table of Contents Introduction........................3 Rating Label Location........................3 Fuel Quality..........................3 Safety Warnings & Recommendations......................4 Operating Instructions..........................6 Dimensions & Specifications......................6 Control Board Functions.......................7 Automatic Safety Features of Your Pellet Stove................7 Operating Your Pellet Stove......................7 Turning Your Pellet Stove Off......................9 Slider/Damper Set-Up........................9 Routine Cleaning and Maintenance......................10 Technical Installation Instructions......................13 Deciding Where to Locate Your Pellet Appliance................14 Removing Pellet Stove From Pallet....................14... -
Page 3: Introduction
Fuel quality is important, please read the following: Your Enviro pellet stove has been designed to burn ¼” (6mm) dia wood pellets and other organic fuels. DO NOT use this appliance as an incinerator. DO NOT use unsuitable and non recommended fuels, including liquid fuels as this will void any warranties stated in this manual. -
Page 4: Safety Warnings & Recommendations
To prevent the possibility of a fire, ensure that the appliance is properly installed by adhering to the installation instructions. An Enviro dealer will be happy to assist you in obtaining information with regards to your local building codes and installation restrictions. - Page 5 If this power cord should become damaged, a replacement power cord must be purchased from the manufacturer or a qualified Enviro dealer. Be careful that the electrical cord is not trapped under the appliance and that it is clear of any hot surfaces or sharp edges. This unit’s maximum power requirement is 504 watts.
-
Page 6: Dimensions & Specifications
29" (736mm) 26" (664mm) " (601mm) " (928mm) " (619mm) Figure 1: Dimensions of M-55-FS. peciFicationS Input rating when using: Wood Pellets/Corn - 55,000BTU (16.1KW•hr) & Wheat/Barley - 53,000BTU (15.5KW•hr). Table 1: M-55-FS Specifications. Description Fuel type Residential Pellet Heater 6mm (¼”) dia. -
Page 7: Operating Instructions
Operating Instructions ontRoL oaRd unctionS 1. ON/OFF BUTTON: Used to turn the unit ON and OFF manually. 2. COMBUSTION AIR TRIM BUTTON: Increases or Decreases the Fan voltage by 2.5volts on all feed settings. When pressed all lights on Heat Level Indicator will come on except the one that is the set point. - Page 8 Operating Instructions peRating eLLet tove DO NOT OPERATE THE UNIT WITH THE DOOR OR ASH BOX OPEN. Keep hopper lid closed except during re-fuelling. CAUTION: When operating during adverse weather, such as high winds or freezing rain, if the unit exhibits dramatic changes in combustion stop using the unit immediately.
-
Page 9: Turning Your Pellet Stove Off
Operating Instructions previous MANUAL setting. If the thermostat contacts remain open, the stove automatically begins its shutdown routine. The stove will re-light when the thermostat contacts close again. uRning eLLet tove • MANUAL and HI / LOW mode: To turn the unit OFF, simply press the ON / OFF button. This will stop the feed of pellets. -
Page 10: Routine Cleaning And Maintenance
10. Set the fire grate in place, it should sit level on the front and back of the burn pot liner. Lock it in with the lever on the burn pot. 11. Close the door Figure 8: M-55-FS Burn Pot Assembly. - Page 11 Open the door by lifting the handle. The glass can be cleaned by wiping down the outside and inside of the Figure 9: M-55-FS Heat Exchanger Cleaning. glass with a dry soft cloth. If the glass has build up that can not be removed with only the cloth, clean the glass using paper towel and a gas appliance glass cleaner, this may be purchased through most dealers.
- Page 12 7. Close the firebox and ash Burner System pan doors and secure. Figure 10: M-55-FS Exhaust Passages. BLOWER MECHANISMS (Annually) Unplug the stove then open the right and left side panels to access the two blowers. Remove the two (2) hex head screws from the upper &...
-
Page 13: Technical Installation Instructions
Technical installation instructions FoR QuaLiFied inStaLLeRS onLy... -
Page 14: Deciding Where To Locate Your Pellet Appliance
Installation eciding HeRe to ocate youR eLLet ppLiance 1. Do not install the stove in a bedroom or room where people sleep in. 2. Locate the stove in a large and open room that is centrally located in the house. This will optimize heat circulation. -
Page 15: Clearances To Combustibles
Alcove Minimum Height 60 inches (152 cm) The unit must be installed with a minimum of 6” (152 mm) of floor protection in front of and to the sides of Figure 4: M-55-FS Clearance to Combustibles. the door opening. edeStaL... -
Page 16: Vent Termination Requirements
Installation eRmination eQuiRementS IT IS RECOMMENDED THAT YOUR PELLET STOVE BE INSTALLED BY AN AUTHORIZED DEALER/INSTALLER. Table 2: Use in conjunction with Figure 7 for allowable exterior vent termination locations. Letter Minimum Clearance Description 24 in (61 cm) Above grass, top of plants, wood, or any other combustible materials. 48 in (122 cm) Beside/below any door or window that may be opened. -
Page 17: Outside Fresh-Air Connection
" 5" " (465mm) (128mm) (161mm) FRESH AIR INTAKE. " Base of unit to center of intake (378mm) ” (378 mm) Center of unit to center of intake 5” (128 mm) Figure 9: M-55-FS Inlet and Outlet Location. " (290mm) -
Page 18: Mobile Home Installation
Installation obiLe nStaLLation ● Secure the heater to the floor using the four (4) holes in the pedestal. ● Ensure the unit is electrically grounded to the chassis of your home (permanently). ● Do not install in a room people sleep in. ●... -
Page 19: Horizontal Exhaust Through Wall Installation
Installation oRizontaL XHauSt HRougH nStaLLation Vent installation: install vent at clearances specified by the vent manufacturer. A chimney connector shall not pass through an attic or roof space, closet or similar concealed spaces, or a floor, or ceiling. Where passage through a wall or partition of combustible construction is desired, the installation must conform to CAN/CSA-B365 Installation Code for Solid-Fuel-Burning Appliances and Equipment and with all local regulations, including those referring to regional and national. - Page 20 Installation 8. The pipe must extend at least 12” (30 cm) away from the building. If necessary, bring another length of pipe to the outside of the home to connect to the first section. Do not forget to place high temperature silicone around the pipe that passes through the thimble if required by vent manufacturer.
-
Page 21: Recommended - Through Wall With Vertical Rise And Horizontal Termination Installation
Installation Recommended - t HRougH eRticaL iSe and oRizontaL eRmination nStaLLation Termination cap 90°elbow Wall framing A 45° down elbow with a screen may be used in Vertical section of vent pipe place of the termination cap (or stainless steel Wall strap termination hood). -
Page 22: Outside Vertical Installation
Installation utSide eRticaL nStaLLationS To accomplish an outside vertical pipe installation, follow the “h ” orizontal xhauSt hrough nStallationS section and then finish it by performing the following (refer to Figure 16). 1. Install a tee with clean out on the outside of the house. 2. -
Page 23: Inside Vertical Installation
Installation nSide eRticaL nStaLLationS 1. Place the unit on the hearth pad if a hearth pad is to be used (or on solid material if installed on a carpeted surface) and space the unit in a manner so when the pellet vent is installed vertically, it will meet the minimum clearance from a combustible wall stated by the vent manufacturer. -
Page 24: Hearth Mount Installation
Installation eaRtH ount nStaLLation Damper Removed or Fastened Open Mantel Minimum (8") 200mm from top of stove Clean-out tee Min (6") 150mm Fresh-air intake should com from chimney. If holes already exist fresh-air intake Floor can be taken through back Protection of the fireplace or through the ash dump. -
Page 25: Troubleshooting
Troubleshooting DO NOT: ● Service the stove with wet hands. The stove is an electrical appliance, which may pose a shock hazard if handled improperly. Only qualified technicians should deal with possible internal electrical failures. ● Do not remove from the firebox any screws without penetrating oil lubrication. WHAT TO DO IF: 1. - Page 26 Troubleshooting • Exhaust Temperature Sensor failure. Bypass sensor located on Exhaust Blower, if stove now operates properly, the unit may require cleaning or a new sensor. Contact your local dealer for service. • Check the agitator to make sure it is turning properly 3.
- Page 27 Troubleshooting 8. Ignitor - the pellets will not light. • Check the line fuse to see if it has blown. NOTE: The ignitor should be bright orange in color. • Everything else in the stove operates but the ignitor will not light the pellets. •...
-
Page 28: Wiring Diagram
Wiring Diagram Black Brown 2µF Capacitor Black Exhaust Blue Combustion Temperature Brown Blower Blue Blue Sensor Black White 120V Ground Air Pump White Plug Green Ground Ignitor White Thermostat Ground 5 Amp White Agitator Blue/Yellow Black Motor White Auger Yellow Yellow Motor Purple... -
Page 29: Parts List
EC-001 ⅝” I.D. Auger Brass Bushings (Set of 2) 50-1806 Stainless Steel Cast Agitator with Coupler 50-1697 Convection Blower 80mm 50-2064 Enviro Gel Decal 50-322 Auger With Paddles 50-1161 Ignitor Coil Type - 400 Watt 50-2142 Auger Stops (Clear Rubber) - Page 30 Parts List Reference # Description Part # ¼” Spring Pin 50-1701 Agitator Bushing Left Side 50-1703 Lower Ash Pan Door Complete 50-2071 Glass Only 14.88” X 11.36” (378x289mm) 50-2056 Glass Retainer 50-2065 Burn Pot Scraper Tool 50-1254 Door And Ash Door Gasket Firm - 10ft (3.05m) 50-2058 Ash Pan...
-
Page 31: Parts Diagram - Components
Parts Diagram - Components... -
Page 32: Parts Diagram - Cast
Parts Diagram - Steel... -
Page 33: Warranty
Exclusions conditions herein set forth, this product against defects in material and workmanship An expanded list of exclusions is available at www.enviro.com/help/warranty.html during the specified warranty period starting from the date of original purchase at retail. This warranty does not cover: In the event of a defect of material or workmanship during the specified warranty period, ƒ... -
Page 34: Installation Data Sheet
SERIAL NUMBER:___________________________ _________________________________________ DATE OF PURCHASE: _____________ (dd/mm/yyyy) ADDRESS: DATE OF INSTALLATION:___________ (dd/mm/yyyy) _________________________________________ MAGNEHELIC AT INSTALL:___________________ _________________________________________ INSTALLER’S SIGNATURE: _________________________________________ _________________________________________ PHONE:___________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.enviro.com January 23, 2013 C-13845...
