Development Kit Inventory Checklists; Intel® Q35 Express Chipset Development Kit Block Diagram; Development Kit Hardware Items - Intel Core 2 Duo User Manual

Intel Core 2 Duo Processor and Intel Q35 Express Chipset—Development Kit Hardware Features
Figure 2. Intel® Q35 Express Chipset Development Kit block diagram
2.3

Development Kit Inventory Checklists

This section describes major hardware items which should be available on this
development kit.
Table 3.

Development Kit Hardware Items

1x 4-Layer Micro-BTX form factor (targeted dimensions: 10.5" x 10.4") motherboard
1x Intel® Core
2x 1 GBytes DDR2 800 DIMM
1x BTX Heatsink with fan
1x CD-ROM contain chipset drivers (this include Intel® GMA3100 driver)
8x hex standoffs and 4x screws for bench top usage
® TM
Intel Core 2 Duo Processor and Intel
User's Manual
12
TM
2 Duo E6400 Processors in the LGA775 Socket
®
Q35 Express Chipset Development Kit
October 2007
Order Number: 318476001US
