MT-7600 Fiber Optic Power Meter
User's Manual
st
,
1
Edition
2011
©2011 Copy Right by Prokit's Industries Co., Ltd.

Advertisement

loading
Need help?

Need help?

Do you have a question about the MT-7600 and is the answer not in the manual?

Questions and answers

Summary of Contents for Pro'sKit MT-7600

  • Page 1 MT-7600 Fiber Optic Power Meter User’s Manual Edition 2011 ©2011 Copy Right by Prokit’s Industries Co., Ltd.
  • Page 2: Specifications

    Application The MT-7600 Fiber Optic Power Meter is used for field or laboratory testing of fiber optic systems at typically 850, 1300, 1310 and 1550 nm. It features superb measurement confidence, ease of use and reduced cost of ownership, and is for use by installers, technicians and engineers, telecom construction, maintenance, CATV, LAN and R&D applications.
  • Page 3: Names Of Parts

    Names of Parts 1. Multi-connector (ST, FC, SC three in one) 2. LCD. 3. Power ON/OFF button. 4. Function button keypad. 5. Back-light push button. 6. Battery cover Operation 1. Press the On/Off key to turn on the Power Meter 2.
  • Page 4: Lcd Display

    Appendix: Optical fiber loss measurement Step 1- Optical Reference Level Turn on optical power meter and press the λ key to select the wavelength. Turn on optical light source and select the wavelength. Wait for 1-2 minutes until it stabilize. Select a piece of patch cords, which is used to connect with the light source.
  • Page 5 3. dBm: Display currently selected unit as dBm. 4. Watt mode: When watt is selected, mW, uW, nW, pW, will be displayed subject to the size of signal. 5. dB mode: When dB is displayed , difference between two signals can be measured.
  • Page 6 CARE OF YOUR INSTRUMENT 1. Always clean the mating connector tip and ferrule before mating, using approved materials. Clean the instrument using alcohol or other non solvent cleaning agents. Acetone or other active solvents may damage the case. When not in use, keep connectors covered and away from dust.
  • Page 7 MT-7600 光纖功率表 操作說明書 序言 感謝您購買此光纖功率錶. 在操作此光纖功率錶前請先閱讀使用說明書, 以確保您能安全及正確地操作此光纖功率錶. 規格 使用 InGaAs 光二極體並具有既 寬與平的反應曲線. 測量波長: 850nm , 1300nm , 1310nm, 1550nm. 測量範圍: +3dBm ~ -55dBm , 2mW ~ 4nW. 解析度: 0.01. 精度:0.3dBm. 連接器: ST+SC+FC 三合一. 過載指示. 低電力指示. 自動關機. 10. 背光功能. 11. 電源︰ 4 顆 1.5V 電池 (不含) 操作/儲存溫度(濕度)︰-0 ~ 50°C / -20 ~ 60°C (0~80%RH)
  • Page 8 各部名稱 光纖功率錶的連接器. 螢幕. 光纖功率錶的電源開關. 光纖功率錶的功能鍵. 背光的按鍵. 電池蓋. 標準光源 操作 一般光纖網路量測 連接光纖網路線到光纖功率表 按下電源鍵控制電源的開與關. λ:選擇適合的波長,重複按可 850,1300,1310,1550nm 跳動.選 擇與光纖網路相同的波長 依需求選擇 dBm 或是 W 單位 按 db 鍵即可自動計算出 dB 值...
  • Page 9 ***比較標準光源並且計算光纖功率的損失 1. 選擇一條跳接線,連接光纖功率錶及標準光源. 2. 讀出光纖功率錶的值定義為P1. 3. 使用光纖跳接線連接成光纖網路. 4. 在另一端,使用光纖功率錶連接光源錶,定 義 值 為 P2. = P2 - P1 Loss 有接點光纖網路線 標準光源 LCD 配置說明...
  • Page 10 低電力符號:當此符號產生時,1.5V 電池請立即更換.以維持測量的準確性. 波長:螢幕會顯示測量的波長. dBm:螢幕顯示的單位是: dBm. Watt模式:當您使用watt模式時,將有mW, uW, nW, pW供選擇. dB模式:當您選擇dB模式時,您可以測量兩個不同的信號. 測量顯示:螢幕可以顯示測量值. 自動關機:當自動關機顯示時,意即在沒按下任何按鍵情況下,主機 將在 40 分鐘後自動關機. 按鍵配置說明 光纖功率錶的電源鍵:按下電源鍵可控制光纖功率錶的開與關. dBm/Watt:按下此按鍵可切換dBm或Watt. λ此按鍵可選擇波長:850nm,1300nm, 1310nm, 1550nm. dB可測量兩個不同的信號. 按下此按可控制背光的開與關.在不關閉背光的情況下,背光光源可持 續點亮約50秒後即會自動關閉背光功能.
  • Page 11 保養及安全須知 使用拭鏡紙及酒精清潔連接器,並使用空氣球吹乾.不可使灰塵沾在連接器上 面. 當主機不使用時,請將主機擦拭後放入手提箱內,假如有灰塵沾在連接器內,將 會增加測量的不確定性. 假如您長時間不使用主機.請記住將電池取出以避免發生可能的危險. 注意事項 連接器請勿重壓或碰撞.也不能接觸化學藥品或沾上灰塵, 連接器表面請用拭淨 紙擦拭. 請使用鹼性電池以增加使用的時間.當低電力符號顯示時,請立即更換電池. 假如使用外部的電源時,請選擇正確規格的整流器以避免發生危險. 請勿將主機置於不允許的環境下操作. 本機為一高精密的測量儀器,請不要自行打開它,否則品質無法確保.
  • Page 12 ©2011 Prokit’s Industries Co., LTD. All rights reserved 2011001(T)
