Pro'sKit NT-311 Manual

NT-311 Digital Temperature Humidity Meter

SPECIFICATION:


Temperature Range: -10℃～+50℃ ± 1℃ (+14℉ ～ +122℉ ±1.8℉)

Humidity Range: 10% ~ 95% RH ±5%

Power-supply: 1.5V (AAA size) x 1

FUNCTIONS:


Temperature/ humidity display

Temperature unit: ℃/℉ changeable

Memory of MAX/MIN values of temperature & humidity

Temp. & humidity value capture: 10secs

Eight-minutes snooze

Clock & date and weekday display function, automatic exchanging in 5
seconds between clock & date, 2 modes of time display: 12h / 24h

Hourly alarm function and everyday alarm function

OPERATIONS

Button description
MODE:
1) Switch clock, alarm, 12/24h, and date.
2) Press to display the alarm clock.
3) Long press to set up the minute, hour,
12/24h and date.
ADJ:
1) Turn on/off the alarm and hourly chime.
2) Adjust the value.
℃/℉: Press to convert the temperature unit.
MIN/MAX: 1) Press to display the Max./Min. temp. & humidity in memory
2) Press one time to display the Max. value, two times for Min.
value, and three times to exit.
SNOOZE
1) Press to turn on 8-minutes snooze function when alarm buzzing

Setup

TIME SETUP: 1) Long press button MODE to set the time.
12/24H SETUP: 1) Long press button MODE to set 12/24h.
DATE SETUP: 1) Long press button MODE to set the date, and the
ALARM CLOCK SETUP
1) Press button MODE to switch alarm.
2) Long press button MODE to set the time.
3) Press button ADJ to adjust the value.
4) Press button MODE to exit.
ALARM and hourly alarm on/off:
1) Press button MODE to switch alarm.
2) Press button ADJ to on/off alarm or hourly alarm..
3) Press button MODE to exit.
4) Press any button (except SNOOZE) to turn off the alarm when buzzing.
SNOOZE FUNCTION SETUP
when alarm buzzing, press the button SNOOZE to turn on 8-minutes
snooze function
MAX/MIN TEMP. & HUMIDITY DISPLAY
1. Press MAX / MIN one time to display the Max. value, and then display
the Min. value, and the third to exit
2. Press MAX / MIN two times to display the Min. value.
3. Press MAX / MIN three times to exit.
4. Long press button MAX / MIN to delete the Max./Min. temp. & humidity
in memory.

ATTENTIONS:


It will return all the setting to default when replace the battery.

We do not notice if any technical change is applied in this meter.
NT-311 溫濕度計使用手冊
產品規格
溫度測量範圍: -10℃~+50℃ ± 1℃(+14℉~ +122℉ ±1.8℉ )
濕度測量範圍: 10%RH~95%RH ±5%
電源:電池 1.5V（AAA）× 1 個
基本功能
1、 日曆顯示、星期顯示、12/24 小時制時鐘功能、每日鬧鐘、整點報時功能
2、 ℃/℉溫度顯示
3、 8 分鐘貪睡功能
4、 溫度與濕度取樣週期:10 秒
5、 最高/最低溫度與相對濕度顯示
按鍵說明
MODE 鍵:
1) 切換時鐘顯示模式，設置時鐘、鬧鐘、年/月/日與 12/24 小時.
2) 按 MODE 鍵 1 秒，顯示鬧鈴設定時間。
3) 長按 MODE 鍵 2 秒，可設定分→小時→12/24→年→月→日→退出設置。
ADJ 鍵：1) 開關鬧鐘和整點報時
2) 用於各項功能鍵，數值設置調整
SNOOZE 鍵
1) 鬧鐘響鬧時，按此鍵可啟動 8 分鐘貪睡功能。
℃/℉鍵：切換溫度℃/℉顯示方式。
2) Press button ADJ to adjust the value.
2) Press button ADJ to adjust the value.
weekday will be adjusted automatically.
2) Press button ADJ to adjust the value.
