Signal Connections

To avoid irregular operation and /or damage to the display, please insure correct video is being
supplied as shown on the following page.
HD-15 Video Connector
S-Video Connector
Pin
HD15(F) Connector
Pin
1
2
3
4
5
S-Video Connector
Signal
1 Ground
2 Ground
3 Luminance
4 Chorminance
Signal Pin
Red Video 6
Green Video 7
Blue Video 8
Not Used 9
Ground 10 Ground
C-Video Connector
C-Video Connector
Pin Signal
1 Ground
2 Composite video signal
6
Signal Pin Signal
Ground 11 Not Used
Ground 12 DDC Data
Ground 13 Analog H Sync
Fused VCC 14 Analog V Sync
15 DDC Clock
