Osd On-Screen Display - VarTech Systems VT064C User Manual

OSD - On Screen Display Cont.
3.1
NO. Button
name
1
Power
2
Menu
3
Select
4
Up
5
Down
NO. Button name
1 Power
2 Menu
3
Select
4
Up
Switch Function
Switch on / off Power
1. First Click: Activate the OSD Main Menu
2. Second Click: Deactivate the OSD Main Menu
3. Leave Sub-Menu / back to Main Menu
Select the value of OSD Main Menu or value of OSD
Sub-Menu and change the value of OSD sub-menu to be
able to modify (toggle key)
1. Move between Main Menu
2. Move between Sub-Menu inside Main Menu
3. Adjustment of Sub-Menu value inside Main Menu
1. Move between Main Menu
2. Move between Sub-Menu inside Main Menu
3. Adjustment of Sub-Menu value inside Main Menu
Table 1
Switch Function
- - -
- - -
Auto Adjust
Reset and Auto Adjust
Table 2
8
