Operating Your Wine Cooler; Setting The Temperature Control - CDA CWC600SS User Manual

Operating Your
Wine Cooler
The Wine Cooler should be placed in a position
where the ambient temperature is between
0-35°C. If the ambient temperature is above or
below this range, the performance of the unit may
be affected. For example, placing your unit in
extreme cold or hot conditions may cause interior
temperatures to fluctuate. The range of 5-18°C
may not be reached.
Note:
• When you use the Wine Cooler for the
first time or restart the Wine Cooler
after having been shut off for a long
time, there could be a few degrees
variance between the temperature you
select and the one indicated on the
LED readout. This is normal and it is
due to the length of the activation time.
Once the Wine Cooler is running for a
few hours everything will be back to
normal.
• If the unit is unplugged, power lost,
or turned off, you must wait 3 to 5
minutes before restarting the unit. If
you attempt to restart before this time
delay, the Wine Cooler will not start.
The Controls of Your Wine Cooler
Power
RUN
Light
Upper Chamber
RUN
Indicator light illuminates to signify the cooling
mode is currently in operation.
Light
To control the inner light turn on/off.
Power
To control this appliance turn on/off.
"Set Upper" Button
Used to set temperature in upper zone.
"Set Lower" Button
Used to set temperature in lower zone.
o o
C C
Set Upper
Set Lower
Lower Chamber

Setting the Temperature Control

The wine cooler has two temperature zones.
•
Upper zone – temperature range 5-12°C
•
Lower zone – temperature range 12-18°C
•
You can set the required temperature in either
zone by pushing the Set Upper or Set Lower
button. When you push the button for the first
time, the LED readout will show the previously
set temperature for that zone (the temperature
preset at the factory is 12°C.
• To set the temperature in the Upper Zone –
Press Set Upper button once. The present
temperature will flash. Scroll through the
temperature settings until you reach the
required setting. The temperature will
decrease by 1°C every time the button
is pressed until minimum temperature is
reached, at which point it will then revert back
to its maximum setting and start again.
• To set the temperature in the Lower Zone –
Press the Set Lower button and follow the
instructions above.
• To view the temperature set in either zone
at any time, press the corresponding "Set
Upper" or "Set Lower" button, the "Set"
temperature will temporarily flash in the LED
display for 5 seconds.
Shelves
• To prevent damaging the door gasket, make
sure the door is fully opened when pulling
shelves out.
• For easy access to the bottles stored, pull
the shelves out. Shelving is designed with
an emergency stop to prevent them being
removed too far when loaded.
8
