Reversing the Door
Swing of Your Appliance
Should you desire to reverse the opening
direction, please follow the instructions below .
Figure 1
Figure 3
Lock Screws
1
Right Lower Hinge
2
Door Shaft Assembly
3
Right Top Hinge
4
Note: All parts removed must be saved to
allow the door swing to be reversed.
Figure 2
Figure 4
Door
5
Cabinet
6
Left Top Hinge
7
Left Lower Hinge
8
7
1. Open the glass door and remove the two screws
under the right bottom corner of the glass door
that are used to hold the right lower hinge to the
glass door. Be careful to support the glass door
with hands to prevent it dropping after removing
the screws. (Figure 1)
2. Pull down to remove the glass door and place
it on a padded surface to prevent scratching it.
(Figure 2)
3. Remove the right top hinge and right lower
hinge. (Figure 3). Remove the left top hinge
and left lower hinge from the plastic bag that
includes the instruction manual then install them
at the designated positions at the left side of
cabinet.
4. Turn around the glass door 180° and reinstall it.
