- Page 1 Gas cookers RC 9300 .. Users Operating Instructions Installation instructions Before operating this cooker, please read these instructions carefully...
- Page 2 Dear Customer Thank you for choosing one of our appliances, carefully designed and built by our specialist staff and thoroughly tested to satisfy your cooking requirements. We suggest that you read this Instruction Booklet so that you will understand fully how to operate your appliance. Please keep the booklet handy.
-
Page 3: Table Of Contents
Contents Model RC 9300 .. Page Number Introduction ..........4 Assembling the backguard . -
Page 4: Introduction
Introduction Congratulations on your purchase of this cooker which has been carefully designed and produced to give you many years of satisfactory use. Before using this appliance it is essential that the following instructions are carefully read and fully understood. We would emphasise that the installation section must be fully complied with for your safety to ensure that you obtain the maximum benefits from your appliance. -
Page 5: Features And Technical Data
Features and technical data Gas burners 1. Auxiliary burner (A) 1,00 kW 2. Semi-rapid burner (SR) 1,75 kW 3. Rapid burner (R) 3,00 kW 4. Triple-ring burner (TR) 3,50 kW Fig. 2... -
Page 6: Control Panel
Control panel Fig. 3 CONTROL PANEL - Controls description 1. Gas oven / gas grill control knob 2. Minute counter 3. Front left burner control knob 4. Rear left burner control knob 5. Front central burner control knob 6. Rear central burner control knob 7. -
Page 7: How To Use The Hob Burners
How to use the hob burners Hob burners Each hob burner is controlled by a sep- arate gas tap operated by a control knob (fig. 5) which has 3 positions marked on the control panel, these are: – Symbol : tap closed (burner off) –... - Page 8 Choice of burner The burner must be chosen according to the diameter of the pans and energy required. Burners Pan diameter Auxiliary 12 ÷ 14 cm Semi-rapid 16 ÷ 24 cm Rapid 24 ÷ 26 cm Triple-ring 26 ÷ 28 cm max 36 cm Fig.
- Page 9 Correct use of triple-ring burner The flat-bottomed pans are to be placed directly onto the pan-support. To use the WOK you need to place the proper stand in order to avoid any faulty operation of the triple-ring burner (Fig. 7 - 8). IMPORTANT: The special grille for wok pans (fig.
-
Page 10: How To Use The Gas Oven
How to use the gas oven Lighting the oven gas burner The thermostat allows the automatic control of the temperature. The gas delivery to the oven burner is controlled by a two way thermostatic tap (oven and grill burners) with flame-failure device. To light the oven burner operate as follow: 1) Open the oven door 2) Lightly press and turn the thermostat knob anti-clockwise to max position “... - Page 11 Oven cooking temperatures APPROX. HEAT OF TYPE OF DISH TO COOK MARK TEMP . OVEN 150°C Very cool Meringue cakes, oven slow cooking items • 165°C Cool or Milk puddings, very rich fruit slow oven cakes, i.e., Christmas 180°C Cool or Stews, casseroles, braising, slow oven rich fruit cakes, i.e., Dundee...
-
Page 12: How To Use The Gas Grill
How to use the gas grill Lighting the grill gas burner Do not grill with oven door closed. Always fit the heat shield supplied with the cooker under the front panel before commencing operations (Fig. 13). WARNING. The heat shield and the oven door reaches a very high temper- ature whilst in use. -
Page 13: Oven Light
Notes: – The grill burner has only one setting, that is full-on – It is important that the heat shield is fitted the correct way up, as shown in the figure Fig. 13 IMPORTANT WARNING For best results when using the grill, place the shelf on the second level and when using the grill pan handle avoid contact with the heat shield which will be HOT during use Oven light... -
Page 14: Rotisserie
Rotisserie This is used for spit roasting under the grill and comprises: – an electric motor fitted to the rear of the oven – a stainless steel skewer provided with slide-out heatless handgrip and two sets of adjustable forks – a skewer support to be fitted in the middle runner. -
Page 15: Do' S And Do Not' S
Do’ s and do not’ s Do’ s and do not’ s • Do not grill with oven door closed. Always fit the heat shield supplied with the cooker under the front panel before commencing operations. • Do read the user instructions carefully before using the cooker for first time. •... -
Page 16: Important Notes
For your safety The product should only be used for its intended purpose which is for the cooking of domestic foodstuffs. Under no circumstances should any external covers be removed for servicing or main- tenance except by suitably qualified personnel. Attention The appliance gets very hot, mainly around the cooking areas. -
Page 17: Care And Maintenance
Care and maintenance Important: As a safety measure, before you start cleaning the cooker be sure to disconnect it from the mains supply. Do not use a steam cleaner because the moisture can get into the appliance thus make it unsafe. The use of suitable protective clothing/gloves is recommended when han- dling or cleaning of this appliance. - Page 18 Enamelled parts All the enamelled parts must be cleaned with a sponge and soapy water only or other non-abrasive products. Dry preferably with a microfibre or soft cloth. Stainless steel, aluminium, painted parts and silk- screen printed surfaces Clean using an appropriate product. Always dry thoroughly. Stainless steel surfaces: can be cleaned with an appropriate stainless steel cleaner.
- Page 19 Burners They can be removed and washed only with soapy water. Detergents can be used but must not be abrasive or corrosive. Do not use abrasive sponges or pads. Do not put in dishwasher. After each cleaning, make sure that the burner-caps, as well as the burners, have been well wiped off and CORRECTLY POSITIONED.
- Page 20 Removal of the inner glass door panel – The inner glass door panel can easily be removed for cleaning by unscrewing the four screws (fig. 20). – When re-assembly ensure that the inner glass is correctly positioned and do not over tighten the screws.
- Page 21 Inside of oven The oven should always be cleaned after use when it has cooled down. The cavity should be cleaned using a mild detergent solution and warm water. Suitable proprietary chemical cleaners may be used after first consulting with the manufacturers recommendations and testing a small sample of the oven cavity.
- Page 22 Removing the oven door Fig. 25a Please operate as follows: • Open the door completely. • The swivel retainers of the rh and lh hinges (fig. 25a) are hooked onto the metal bar above them (fig. 25b). • Lift the oven door slightly. The noch on the bottom of the hinge will disen- gage (fig.
-
Page 23: For The Installer
FOR THE INSTALLER The appliance may be installed in a kitchen, Kitchen/diner or a bed sitting room, but not in a room or space containing a bath or a shower. The appliance must not be installed in a bed-sitting room of less than 20 m The appliance is designed and approved for domestic use only and should not be installed in a commercial, semi commercial or communal environment. -
Page 24: Location
Location This cooker has class “2/1” overheating protection so that it can be installed next to a cabinet. If the cooker is installed adjacent to furniture which is higher than the gas hob cook- top, a gap of at least 200 mm must be left between the side of the cooker and the fur- niture. -
Page 25: Fitting The Adjustable Feet
Fitting the adjustable feet The adjustable feet must be fitted to the base of the cooker before use. Rest the rear of the cooker an a piece of the polystyrene packaging exposing the base for the fitting of the feet. Fit the 4 legs by screwing them Fig. - Page 26 WARNING Be carefull: do not lift the cooker by the door handle when raising to the upright position (fig. 30). WARNING When moving cooker to its final posi- tion DO NOT DRAG (fig. 31). Lift feet clear of floor (fig. 29). Fig.
-
Page 27: Stability Bracket
Stability bracket We recommend a stability bracket is fitted to the cooker. The type shown in fig. 33 can be purchased from most plumbers merchants and do it yourself (D.I.Y.) shops. Existing slot in rear of cooker Brackets Fig. 33 Dotted line showing the position of cooker when fixed Outline of cooker... -
Page 28: Provision For Ventilation
Provison for ventilation ✓ The appliance should be installed into a room or space with an air supply in accor- dance with BS 5440-2: 2000. ✓ For rooms with a volume of less than 5 m - permanent ventilation of 100 cm free area will be required. -
Page 29: Gas Installation
Gas installation IMPORTANT NOTE This appliance is supplied for use on NATURAL GAS or LPG (check the gas regulation label attached on the appliance). ✓ Appliances supplied for use on NATURAL GAS: they are adjusted for this gas only and cannot be used on any other gas (LPG) without modification. -
Page 30: Gas Connection
Gas connection The installation of the gas appliance to Natural Gas or LP Gas must be carried out by a C.O.R.G.I. registered installer. Installers shall take due account of the provisions of the relevant British Standards Code of Practice, the Gas Safety Regulations and the Building Standards (Scotland)(Consolidation) Regulations issued by the Scottish Development Department. - Page 31 Cat: II 2H3+ Gas connection The gas supply must use the nearest gas inlet pipe which is located at the left or the right hand side at the rear of the appliance (figs. 34, 36). The hose should also be connected in such away that it does not touch the floor. To screw the connecting tube operate with two spanners (fig.
- Page 32 IMPORTANT PRESCRIPTIONS FOR GAS CONNECTION Rear wall Suggested area for gas mains connection Fig. 36...
-
Page 33: Conversion To Natural Gas Or To Lpg
Conversion to Natural Gas or to LPG Injectors replacement of top burners Every cooker is provided with a set of injectors for the various types of gas. Injectors not supplied can be obtained from the After-Sales Service. Select the injectors to be replaced according to the table at page 35. The nozzle diameters, expressed in hundredths of a millimetre, are marked on the body of each injector. - Page 34 Adjusting of the minimum of the top burners Considering that in the minimum position the flame must have a length of about 4 mm and must remain lit even with a quick turn from the maximum position to that of mini- mum.
- Page 35 Table for the choice of the injectors Cat: 2H3+ G 30 - 28-30 mbar G 20 Nominal Reduced BURNERS G 31 - 37 mbar 20 mbar Power Power Ø injector By-pass Ø injector By-pass Ring opening Ring opening [kW] [kW] [mm] [1/100 mm] [mm]...
- Page 36 Replacement of the oven burner injector According to the type of gas, the oven injector must be similarly replaced, as stated on the “Table for the choice of the injectors”, operating as follows: – remove the oven bottom. – unscrew and remove the burner fixing screw A (fig. 40). –...
- Page 37 Replacement of the grill burner injector – Unscrew and remove the burner fixing screw ‘C’ (fig. 42). – Slacken screw ‘D’ (fig. 42). – Move and gently suspend the burner as shown in figure 43. Take care not to dam- age the wire to the ignition electrode and the safety valve probe.
- Page 38 Fig. 44 Primary air of the oven burner With a screwdriver untighten the screw (fig. 44) and move the air ring forward or back- ward to close or open the air flow, accord- ing to the “Table for the choice of the injec- tors”.
-
Page 39: Lubrication Of The Gas Taps
Regulating of the oven minimum Considering that in the minimum position the flame must have a length of about 4 mm and must remain lit even with a brusque passage from the maximum position to that of minimum. To be effected only for the oven burner (as the grill burner has an only fixed input) operating on the thermostat as follows: –... -
Page 40: Electrical Installation
Electrical installation For your safety please read the following information: This appliance must be installed by a qualified technician according with the current local regulations and in compliance with the manufacturer instructions. This appliance is supplied with a moulded 13 amp three pin mains plug with a 3 amp fuse fitted. - Page 41 Electrical feeder cable connection The operations must be executed by a qualified technician. To connect the supply cable: - Remove the screws securing the cover “A” on the rear of the cooker (fig. 48). - Feed the supply cable through the cable clamp “D”. The supply cable must be of a suitable size for the current requirements of the appliance;...
-
Page 42: Appliance Servicing
Appliance servicing CDA provide a quality and effective after-sales service to cover all your servicing needs. Please attach your receipt to this page for safekeeping. Please help us to help you by having the following information available when booking a service-call: 1. -
Page 43: Guarantee
CDA and the labour will be charged at the commercial rate applicable at the time of repair. - Page 44 Descriptions and illustrations in this booklet are given as simply indicative. The manufacturer reserves the right, considering the characteristics of the models described here, at any time and without notice, to make eventual necessary modifications for their construction or for commercial needs.
