Physical Layout

1. Line In
(blue) – Connect to the audio output of a stereo receiver, CD
player, etc.
2. Mic In
(pink) – Connect to the microphone (Mono).
3. Front-Speaker
audio-in of a stereo receiver.
4. Rear-Speaker
channel speaker mode is enabled.
5. Center/Sub-woofer
sub-woofer when 6 channel speaker mode is enabled.

Internal Header Connectors

(green) – Connect to front speakers or earphones or
(black) – Connect to the rear speakers when 4 or 6
(orange) – Connect to the center speaker and
J10
J11
J12
Analog CD/IN (L-G-G-R)
Analog CD/IN (G-R-G-L)
Aux In
