Instruction Manual
5 Channel Low Profile PCI Sound Card – 24 Bits
PCISOUND5LP
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 06/21/2011
Advertisement
Table of Contents
Related Manuals for StarTech.com PCISOUND5LP
Summary of Contents for StarTech.com PCISOUND5LP
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 06/21/2011...
- Page 2 Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges...
-
Page 3: Table Of Contents
Table of Contents Introduction ................................1 Packaging Contents ..........................1 System Requirements ..........................1 Installation................................1 Hardware Installation ..........................2 Driver Installation ............................2 Physical Layout ..............................3 Internal Header Connectors .......................3 Specifications ..............................4 Technical Support ............................5 Warranty Information ............................5 Instruction Manual... -
Page 4: Introduction
It is recommended that you remove any previously installed sound card and drivers/software prior to installing the PCISOUND5LP sound card to avoid any conflicts. If previously installed drivers are not removed, the PCISOUND5LP sound card may not function properly. (Note: If your computer has on-board sound you may need to disable it on the motherboard. -
Page 5: Hardware Installation
Run. Type “D:\SOUND\VT1723\setup.exe”. (Assuming you have placed the CD in CD-ROM drive D:). 3. Follow any on-screen instructions to complete the software installation. 4. Restart your system. 5. Once you have rebooted the computer, the PCISOUND5LP sound card will be ready to use. Instruction Manual... -
Page 6: Physical Layout
Physical Layout 1. Line In (blue) – Connect to the audio output of a stereo receiver, CD player, etc. 2. Mic In (pink) – Connect to the microphone (Mono). 3. Front-Speaker (green) – Connect to front speakers or earphones or audio-in of a stereo receiver. -
Page 7: Specifications
Specifications Bus Interface PCI v2.2 (5V) 1 x Aux-In header Internal Connectors 2 x Analog CD/IN header 5 x 3.5mm Mini Jack External Connectors (Line-In, Mic, Front Out, Rear Our, Center/Sub Out) Chipset VIA Tremor VT1723 Full Duplex: 6 output streams, 2 input Duplex Mode streams Playback: 96k/24-bit... -
Page 8: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 9 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
