- Page 1 Slot Saver PCI Card 2 Port SATA, Single Channel ATA/133 Slot Saver PCI Card PCISATA2A133 Instruction Manual Actual product may vary from photo...
- Page 2 StarTech.com Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question.
-
Page 3: Table Of Contents
Troubleshooting ..........5 Accessory Products from StarTech.com ......6 Technical Support . -
Page 4: Introduction
Instruction Manual Introduction Thank you for purchasing a StarTech.com Slot Saver PCI card. This product allows you to add 2 Serial ATA (SATA) and 3 FireWire 400 ports to your computer using a space- saving single card design. Perfect for users looking to upgrade their computers to handle demanding high-speed devices, this card offers easy Plug and Play installation and the ability to connect peripherals using a variety of popular interfaces. -
Page 5: Installation
Instruction Manual I n s tallation This section will guide you through the installation of your PCI Slot Saver card. Please read through the instructions carefully and complete each step in the order listed. If you are installing the card in a low profile slot, remove the standard size bracket and replace it with the included low profile replacement bracket before completing these instructions. -
Page 6: Installing The Drivers
Instruction Manual Installing the Drivers Once you have connected your Slot Saver card, the next time you turn on your computer Windows will automatically detect that you have installed new hardware. Insert the installation disk in your floppy drive, and follow the instructions below to install the required software drivers. -
Page 7: Verifying Your Installation
Instruction Manual Windows 2000/XP Windows 2000/XP includes native support for FireWire and will install the drivers automatically. Ensure that you have the most current Microsoft Service Pack installed. When Windows installs these drivers, you may receive a warning that the files have not been digitally signed. -
Page 8: Specifications
Instruction Manual Specifications Form Factor/Interface PCI 32-bit, ver. 2.2 compliant, 33/66 MHz Full-sized card Standards Supported Serial ATA 1.0 FireWire 400 (IEEE 1394A) Additional SATA Features Watch Dog Timer, SATA to PCI interrupt masking, Spread Spectrum in receiver Maximum Data Transfer Rates 150 MBytes/sec. - Page 9 Instruction Manual Contact your local StarTech.com dealer or visit www.startech.com for cables or other accessories that will help you get the best performance out of your new product. 6 ft. IEEE-1394 FireWire Cable 4-6 pin M/M 1394_46_6 10 ft. IEEE-1394 Firewire Cable 4-6 pin M/M 1394_46_10 15 ft.
- Page 10 Instruction Manual SATA36RA1 24 in. RIght Angle Serial ATA Cable (both ends) SATARA24 36 in. Right Angle Serial ATA Cable (both ends) SATARA36...
-
Page 11: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect,... - Page 12 Revised: 22 September 2004 (Rev. B)
