- Page 1 Installation and Operation Manual York Grande Gas Stove Grande GAS STOVE TO BE LEFT WITH THE CUSTOMER IMPORTANT NOTICE Revision: GB09b © 2007-2008 Broseley Fires Ltd...
-
Page 2: Technical Information
..................…………………..Broseley Fires Ltd. Knights Way, Battlefield Enterprise Park, Shrewsbury, Shropshire SY1 3AB Tel: 01743 461444 Fax: 01743 461446 © 2007-2008 Broseley Fires Ltd... - Page 3 Weight Excluding Optional Canopy ..……………… ..80kg (176 lbs) Maximum Heat Output (approx) ....…………………..5.6 kilowatts © 2007-2008 Broseley Fires Ltd...
- Page 4 3. IMPORTANT INFORMATION APPLIANCE TO BE INSTALLED IN ACCORDANCE WITH NATIONAL REGULATIONS 1. The York Grande is a gas stove designed to run on either natural gas or LPG. The burner units are not interchangeable between the two types of gas. This stove is a radiant convector fuel-effect appliance.
- Page 5 If the appliance has to be located in an opening, there must be a clearance of a minimum of 100mm each side of the stove to any non-combustible materials. The rear of the appliance should have a minimum 75mm air gap between the stove and the back wall. © 2007-2008 Broseley Fires Ltd...
- Page 6 Please check that the following components are included before you start on the assembly : Stove Box 1 x Cast Iron York grande Stove Body 4 x Stove Legs 4 x Sets of Nuts, Bolts and Washers, 2 burner retaining screws...
- Page 7 VENTILATION (GB ONLY) The York grande Gas stove is rated at less than 7 kW and therefore does not normally require additional ventilation in the room (BS5871-part II). © 2007-2008 Broseley Fires Ltd...
- Page 8 Whilst arranging the coals, ensure that the pilot is not obstructed. Broseley Fires Ltd accept no responsibility for any injury sustained whilst handling hot ceramics. Before any ceramics are placed in position ensure that the burner is operating correctly.
- Page 9 IMPORTANT Please follow these instructions carefully. Ceramics that are positioned wrongly could seriously alter the performance of your appliance. Added Coals shown in white for identification only. © 2007-2008 Broseley Fires Ltd...
- Page 10 This log and all the others are in Position EXACTLY as shown in The diagram. . When closing the door of the stove, support its weight in order to get the best seal against the rope. © 2007-2008 Broseley Fires Ltd...
- Page 11 The York Grande Gas stove operates with a traditional permanent pilot light. The knob for ignition and power control is located on the lower right hand side of the stove The pilot light is located at the front middle of the coal matrix.
- Page 12 “OFF” Position.Should the Glass door become broken or damaged in any way, turn your stove off and do not attempt to re-light it. Contact your dealer to organise for a replacement to be fitted before re-lighting the appliance. © 2007-2008 Broseley Fires Ltd...
- Page 13 The G30-ZRPTT is intended for use only with motorized gas combination controls models GV34 (or GV36 retrofitted with a motor). The receiver cable must be firmly plugged onto the flat blade connectors (motor: 6,3 and 4,8mm; micro switch: © 2007-2008 Broseley Fires Ltd...
- Page 14 • Press (p) to turn on the fire (main burner) or to increase flame height • Press (q) to decrease flame or to turn down to pilot. • To incrementally increase or decrease the flame height lightly tap either the (p) or (q) button. © 2007-2008 Broseley Fires Ltd...
- Page 15 If a low flame is sufficient to provide enough warmth to the room, then the appliance will cycle between low fire and off. This allows longer periods with the flame on and provides a more uniform room temperature. © 2007-2008 Broseley Fires Ltd...
- Page 16 Should the appliance turn itself off, wait for a minimum of 3 minutes before attempting to re-light the appliance. In the event of your stove tripping out, consult your installation engineer to have the flue/chimney checked. © 2007-2008 Broseley Fires Ltd...
- Page 17 • See that the burner is burning evenly across the whole of the mesh surface without any coals in place. © 2007-2008 Broseley Fires Ltd...
- Page 18 We hope these instructions are clear and helpful and you are able to enjoy the full benefits of your stove. Please keep this booklet handy for future reference. The manufacture and materials used in building your York Grande gas stove are guaranteed for one year provided the assembly and operation complies with these instructions.
- Page 19 Is the FFD Phial in the correct position in the pilot flame: Does the flame encircle the FFD: Installation Engineers Name: Address Post Code Telephone: Fax: Mobile: Corgi Registered: Yes Number Signed: Date: SY1 3AB Tel: 01743 461444 Fax: 01743 461446 www.broseleyfires.com © 2007-2008 Broseley Fires Ltd...
- Page 20 Please retain your purchase receipt. We will need to see this in the event of a claim under warranty. Broseley Fires Ltd Knights Way Battlefield Enterprise Park Shrewsbury SY1 3AB Telephone + 44 (0) 1743 461 444 Fax + 44 (0) 1743 461 446 © 2007-2008 Broseley Fires Ltd...
